- Page 1 4M SERIES (NETWORK STANDALONE DVR) CLIENT USER’S MANUAL DGP Security 2052 St. John’s Bluff Road, Jacksonville, FL 32246 website: http://www.discount-security-cameras.net email: mailto:Tech@videodvr.com Tel: 866.301.7680 Fax: 904.727.3411...
- Page 2 1. BASIC ENVIRONMENT 1) Minimum PC system requirements: 2) Notice 3) Initial setup for Dynamic IP support 2. 4M CLIENT MENUS 1) Live Display 2) Search (Playback) 3) Pan/Tilt 4) Client Setup 3. CLIENT AVI BACKUP 4. USB MEMORY CLIENT PLAYBACK...
-
Page 3: Minimum Pc System Requirements
(5) After DVR registration, you setup IP or PORT depending on your network environment. (6) After log-in, you click on “MyDVR Go” and you see the added IP and PORT. (7) If you click on your DVR name in the DVR list, you can monitor your DVR. -
Page 4: Function Keys
2. 4M Client Menus 1) Live Display Function Keys Descriptions You can playback the recorded images by time and date. You can pan/tilt specific cameras... - Page 5 You exit the program Function Keys Descriptions You connect to the DVR after “client setup”. You set up information to get connected to the server. You log-in to access the DVR. You can see one channel in full mode. When double-clicked, you can have sequential display.
-
Page 6: Playback Buttons
2) Search (Playback) Playback Buttons Descriptions You can search the dates for recorded data. You playback backward in a fast mode. You stop playback. You playback at a normal speed. (x1) - Page 7 If you click on “DATE” button, you will see a calendar in the left and recorded time data in the right. If you click on a specific date and double-click any time data in the right, you can plackback the recorded time data.
- Page 8 3) Pan/Tilt PAN/TILT Descriptions You can change the Pan/Tilt display modes from 1ch~16ch. Mouse left-button click If you click on a specific channel a red boundary appears. You tilt a camera downward.(The button toggles between tilt and stop.) You tilt a camera upward.(The button toggles between tilt and stop) You pan a camera left.(The button toggles between pan and stop) You pan a camera right.(The button toggles between pan and stop)
- Page 9 You pan/tilt automatically.(The button toggles between pan/tilt and stop) Power on/off. You can zoom in(+) or out(-). You can focus in(+) or out(-). You control the Iris.(Iris availability depends on pan/tilt protocol) You control the Wiper.(Wiper availability depends on pan/tilt protocol) You control the Light.(Light availability depends on pan/tilt protocol) You return to display mode from pan/tilt control.
- Page 10 4) Client Setup...
- Page 11 Status (OSD) on/off Time 3. CLIENT AVI Backup 1) If you mouse-right-click on the image you see the following. You first click on the channel selection. Descriptions DVR IP. DVR network port. Camera name on/off Status(Live, Search) on/off Time on/off...
- Page 12 2) Now you see the channel selection mode. You tick on the channels you would like to record and then click on “OK”. 3) Now, you mouse-right-click on the image again, and you see the following and click on “SAVE AVI”. 4) You are now ready to record the images in AVI format.
- Page 13 5) When you want to stop recording, you mouse-right-click on the image and select “STOP AVI”. (You can check the recorded AVI files under the “C:\” directory with the file name of the current year, month, and date format.) 5. USB MEMORY CLIENT PLAYBACK...
- Page 14 After you insert the recorded USB memory in the client computer, you run the client software. You mouse-right on the software and you see the following. You click on “Open File”, and can find files with extensions of “.DVR” in the memory. Now you can playback the USB backup images.
