Optiview DVRJ4A Specification Sheet

4 Camera JPEG 120fps Duplex Embedded DVR with USB backup
This 4 channel DVR gives you all the quality of the big boys but at an economical price. Unit has user-
friendly controls, motion detection, real-time recording, one touch USB backup, 500gig hard drive, and
remote viewing over network.
Features
Four Channel Input
Duplex (Record and Playback at same time)
Modified JPEG Compression
Remote Viewing via client software (included)
Real Time Display
Up to 120fps Recording Speed
Archiving via USB operation
Watchdog Function
Motion, Event, and Scheduled Recording
Network connection
Specifications
Camera Inputs:
Image Compression:
Operation:
Video Input:
Video Output:
Audio Input:
Audio Output:
Hard Drives:
Display:
Recording Rate:
Recording:
Alarm Inputs:
Alarm Outputs:
Archiving:
Network:
General Unit Dimensions:
Unit Weight:
Operation Temperature:
4
Modified JPEG
Duplex (Record and Playback at same time)
BNC x 4, 1.0Vp-p, 75 ohm
BNC to main monitor
1 input
1 output
1 - 500 Gig drive included, 1 HD Maximum (up to 750
Gigabyte)
30 fps per channel (@720 x 480)
120 fps (@352 x 240), 60 fps (@704 x 240)
Continous, Motion, Event, Schedule
4 TTL
Open/Close/Com
USB 2.0
10/100 Mbps Ethernet (Hardware TCP/IP), DDNS
260mm x 40mm x 220mm (10.24in x 1.58in x
(W x H x D)
8.66in)
4.3 kg (10 lbs)
5°C - 40°C (41°F - 104°F)
Model: DVRJ4A
