System Outline

5.2.3 Ready

1) Host interface is monitored for print commands
2) Heat control
Target temperature (165° C).
Every 40 seconds, temperature value for the previous 250ms is read and a proportional control process is
carried out.
3) Printer is in "Ready" mode entered after warm-up or after completing a print job.
4) System Error check
5) Power save state is entered after timeout
Wakeup condition
When a "wakeup" order is received.
When a cover is opened or closed.
When the level of the paper empty sensor changes.
Heat lamp is off

5.2.4 Processing

There is a preparation stage before processing a print job and after receiving a print command.
1) Start Laser
Run scanning motor.
Check motor ready.
Turn LD on.
2) Start Main Motor, Eraser/PTL ON
Run main motor.
Check lock signal.
Run developer roll motor.
Check lock signal.
3) Turn High Voltage On
Charger ON.
Developer high voltage OFF.
4) Cleaning
Imaging unit and transfer belt cleaning.
5) Jam Check
5-10
