6.4.24 Temperature Sensor (PL 9.16.23)

1. Remove the Front Cover and Top Cover. (6.4.1)
2.
Remove the Rear Cover. (6.4.3)
3. Remove the Duplex Cover. (6.4.4)
4. Remove the LVPS and LVPS Cover. (6.4.7a)
5.
Remove the Main Board Shield. (Steps 1 and 2 of 6.4.11)
6. Remove the DEVE Cover (Door A). (6.4.15)
7. Remove the Laser Cover. (6.4.15.1)
8. Remove the DEVE Drive Assembly. (6.4.11)
9. Remove the Erase Lamp. (6.4.14)
10.
Remove the Waste Toner Auger Assembly. (6.4.18)
11. Remove the Main Drive.
12. Remove all 7 base screws, 1 (3-8 black) and 6 (4-10 silver) and gently lift the rear, right of the frame enough to
feed the harness between the base and the frame.
13. Remove 3 screws securing the DEVE covers rear hinge bracket to the base.
14. Remove the sensor.
