Maintenance and Diagnostics
7.6.2 EDC Menu Map
MOTOR TEST
Main Motor
Dev Motor
Fan Motor
Waste Motor
Tray 2 Motor
MAINTENANCE
New Developer Cluch
MPT Pick-up
Tray 1 Pick-up
Tray 2 Pick-up*
Transfer Roller
* If optional Tray 2-500 Sheet Feeder (SCF Cassette) is installed
7-12
SOLENOID TEST
Y Clutch
M Clutch
C Clutch
K Clutch
Y Solenoid
M Solenoid
C Solenoid
K Solenoid
Feed Clutch
T2 Clutch
(Transfer Roller)
ITB Clutch
(Transfer Belt)
Duplex Solenoid
Tray 1 Clutch
MPT Clutch
Tray 2 Clutch*
REGI. SET
Yellow (+ / - 5)
Magenta (+ / - 5)
Cyan (+ / - 5)
Black (+ / - 5)
SENSOR TEST
Feed Sensor
Exit Sensor
Waste Box Sensor
Side Cover
Tray 1 Empty Sensor
MPT Sensor
Tray 2 Empty Sensor*
Tray 2 Cover Sensor*
HVPS PRINT
Charger
T1
T2
Dev DC
Dev AC
LSU & FUSER TEST
LSU Test
Laser Diode
Fuser
TEST PRINT
Select Tray
Select Pattern
Color Bar 4x4
Solid
Print Pattern
