Parts List

9.18 Pickup Assembly

Pickup Assembly 9.18
No. Part number
0 116-1890-00
1
2
3
4
5
6 116-1897-00
7
8
9 116-1898-00
10
11 116-1947-00
12 116-1951-00
9-38
10
9
7
12
11
1
Qty Part Name and (part description)
1 Tray 1 Pickup ASM
1 Pickup Spring
1 Ground Feed
1 Guide Input
1 Cap Connector L
1 Cap Connector U
1 Actuator Tray 1 Empty
1 Pickup Shaft
1 Guide Paper
1 Tray 1 Empty Sensor
1 Bearing Shaft
1 Bushing
2 Pick Rollers Tray 1
0
5
4
2
6
8
3
