3.6.1 Paper Size and Weights (cont'd)

Tray Support
Tray 1
Tray 2
MPT
Auto Duplex
Output Tray

3.6.2 Print Margins and Skew

Side print position accuracy
Lead print position accuracy
A rectangular box of 189 mm x 256 mm will be used to measure skew.
Simplex
A: Vertical
B: Horizontal
Duplex
1.5 times simplex printing

3.6.3 PC (Host) Specifications

For reliable operation, the following PC configurations are recommended:
Windows 98, Me; Pentioum 166 MHz; 64 MB RAM
Windows NT 4.0, 2000, XP, Server 2003; Pentium 233 MHz; 128 MB RAM
Mac OS9; USB only; Power Macintosh G3, G4, iMac, PowerBook, iBook
All; 200 MB free hard drive space, CD-ROM Drive
Media Types / Capacity
Paper; 250 sheets (20 lb)
Paper; 500 sheets (20 lb)
Paper; 100 sheets
Envelope; 10
Label; 10 sheets
Transparency; 30 sheets
Card stock; N/A
Paper
Paper; 250 sheets (20 lb)
Print Margins
+/- 2.0 mm (+/- 0.08")
+/- 3.0 mm (+/- 0.12")
Skew
Tray 1, 2
< 2.0 mm (+/- 0.08") < 2.0 mm (+/- 0.08")
< 1.5 mm (+/- 0.06") < 1.5 mm (+/- 0.06")
Sizes
A4, Letter
A4, Letter, Legal, Folio, Executive,
A5, ISO and JISB5, A6, Statement,
Monarch, COM10, #9, C5, B5 Env.
and DL
A4, Letter, Folio, Legal
MPT
Specifications
Weight
16 ~ 24 lb
60 ~ 90 gsm
16 ~ 43 lb
60 ~ 163 gsm
20 ~ 24 lb
75 ~ 90 gsm
b
a
