Canon imagePRESS C7011VPS series Operation Manual page 150

Load the required media into the selected tray.
3.
Load the paper stack face up into the inserter.
[50] Face up in the upper tray
IMPORTANT
Make sure that the height of the paper stack does not exceed the loading limit mark at the back
of the paper supply tray.
NOTE
• Only load paper for use as a cover.
• You cannot make copies or prints on paper that is loaded in the inserter.
• Supported media sizes for the upper tray:
- A4, A4R, B5, B5R, or irregular size 182 mm x 182 mm to 297 mm x 330.2 mm
- LTR, LTRR, EXEC or irregular size 7 1/8" x 7 1/8" to 11 11/16 " x 13"
• Supported media sizes for the lower tray:
- 330.2 mm x 482.6 mm, 320 mm x 450 mm (SRA3), 304.8 mm x 457.2 mm, A3, B4, A4, A4R,
B5, B5R or irregular size 182 mm x 182 mm to 330.2 mm x 487.7 mm
- 13" x 19", 12.60" x 17.72", 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC or irregular size 7 1/8" x
7 1/8" to 13" x 19 13/64"
• A maximum of 200 sheets of paper (80 g/m² / 22 lb bond) can be loaded in the upper tray of
the inserter.
• A maximum of 200 sheets of paper (80 g/m² / 22 lb bond) can be loaded in the lower tray of
the inserter.
150 Chapter 7 - Media handling
