19
. SWITCHES/HORN/FUEL UNIT/THERMOSTATIC SWITCH
/TEMPERATURE GAUGE/INSTRUMENTS/LIGHTS
THROTTLE POSTTION SENSOR
V/R
V/R
V/G
4~6
V/B
BACK MIRROR CONTROLLER
W/Y
Y/L
W/Y
Y/L
5.8~11MΩ
V
420~780KΩ
9.3~17MΩ
B/L
7~13MΩ
G
5.8~11MΩ
0.2~0.8Ω

INSTRUMENTS

REMOVAL
Remove the front upper cover. ( 2-5)
Disconnect the instrument wire couplers and
connectors.
Disconnect the speedometer cable.
Remove the four instrument cover and leg
shield screws.
Remove the instruments.
DISASSEMBLY/ASSEMBLY
Remove the three instrument holder nuts.
Remove the holder.
Remove the four screws to disassemble the
instruments and instrument cover.
Assemble the instruments in the reverse order
of disassembly.
INSTALLATION
The installation sequence is the reverse of
removal.
19-7
Unit:KΩ
V/G
V/B
4~6
0~5±1
0~5±1
Unit:Ω
V
B/L
0.2~0.8Ω
9.3~17MΩ
B/L
V
G
Y/L
GRAND DINK 250
T.P.S.
G
W/Y
Wire Couplers
Screws
