PREFACE
This Service Manual describes the
technical features and servicing
procedures for the KYMCO Grand Dink
250.
Section 1 contains the precautions for
all operations stated in this manual.
Read them carefully before any
operation is started.
Section 2 is the removal/installation
procedures for the frame covers which are
subject to higher removal/installation
frequency during maintenance and
servicing operations.
Section 3 describes the inspection/
adjustment procedures, safety rules and
service information for each part, starting
from periodic maintenance.
Sections 5 through 13 give instructions
for disassembly, assembly and adjustment
of engine parts. Section 14 is the removal/
installation of chassis. Section 16 states
the testing and measuring methods of
electrical equipment.
Most sections start with an assembly or
system illustration and troubleshooting
for the section. The subsequent pages give
detailed procedures for the section.
The information and contents included in
this manual may be different from the
motorcycle in case specifications are
changed.
KWANG YANG MOTOR CO., LTD.
OVERSEAS SALES DEPARTMENT
OVERSEAS SERVICE SECTION
GRAND DINK 250
