SPLITMUX-SVDVI-2 DUAL SCREEN SPLITTER
For details of SPLITMUX-SVDVI-2 operation, refer to the corresponding chapter of this
document.
Below is a brief description of the remote transmitter and the keys used for SPLITMUX control.
IR Remote
POWER
ZOOM
CROP
POS
SIZE
VOLUME +
VOLUME -
MUTE
ARROWS
MENU
SEL
EXIT
0..9, DIGITS
INFO
ROTATE
DVI A
RGB A
VIDEO A
DVI B
RGB B
VIDEO B
SINGLE
DUAL
TRI
QUAD
SWAP
FREEZE
PRESET KEYS
4

Quick Start Guide

1. Make sure the SPLITMUX and the Display are both disconnected from power.
2. Connect the SPLITMUX to the Display's DVI, VGA, or YPbPr port as required.
3. Connect the appropriate video sources to input connectors of SPLITMUX (see
"Connections" chapter (pg. 7) for details).
4. Connect audio input/output to the 8-pin miniDIN connector of the SPLITMUX (see
"Connections" chapter (pg. 7) for details).
5. Connect the power source to the Display (refer to Operating Instructions of the Display).
Connect the supplied 12v DC adapter to the SPLITMUX and the power outlet. The LCD
6.
will illuminate and after 5 seconds, the firmware rev will appear. About 15 seconds
later, the SPLITMUX will complete initialization and display the output resolution and
format on the LCD. The last settings of the SPLITMUX will take effect.
Function
Toggles Power On and Off
Brings up Zoom selection for each window 0-100%
Brings up Crop selection for each window 0-100%
Brings up Position selection for each window 0-100%
Brings up Size selection for each window 0-100%
Increases Volume level
Decreases Volume level
Toggles the volume Mute On/Off
Moves the cursor up/down/left/right when Menu is active
Displays Main Menu
Selects option in Menu
Finishes input in dialog panels
Exits 1 menu level
Enters digits when dialog menu is active.
Displays current input/output timings and FW version
Rotates output image by 0, 90, 180, 270 degrees
Selects DVI Side A Input
Selects RGB/YPbPr Input
Selects Video/S-Video Input
Not Available for SPLITMUX-SVDVI-2
Not Available for SPLITMUX-SVDVI-2
Not Available for SPLITMUX-SVDVI-2
Selects 1 window on the output
Selects 2 windows on the output
Not Available for SPLITMUX-SVDVI-2
Not Available for SPLITMUX-SVDVI-2
Swaps the sources between the windows
Freezes the current window
P1 – P4 selects the stored preset
