Page 1: Installation And Operation Manual
® VOPEX Series VOPEX-HDS-x 2, 4, 8, or 16 Port HDMI Splitter Installation and Operation Manual Front and Rear Views of VOPEX-HDS-4 MAN055 Rev Date 4/4/2012... -
Page 2: Table Of Contents
TRADEMARK VOPEX is a registered trademark of Network Technologies Inc in the U.S. and other countries. COPYRIGHT Copyright © 2009, 2012 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. -
Page 3: Introduction
INTRODUCTION The VOPEX-HDS-x HDMI splitter (x= 2, 4, 8 or 16) enables HDMI displays (monitors, HDTV (LCD, PDP), projectors) to be driven by a single digital HDMI source (PC, Cable box, DVD player, Satellite receiver) with no loss of signal. The VOPEX-HDS-x is available with 2,4,8 or 16 output ports. -
Page 4: Connectors And Leds
NTI HDMI Splitter CONNECTORS AND LEDS LABEL CONNECTOR/LED DESCRIPTION 3.5x1.3mm Power Jack for connection of power supply 5V 3.0A Green LED illuminates to indicate proper power to the unit Power HDMI female connector for connection of the display devices HDMI Out... -
Page 5: Installation
NTI HDMI Splitter INSTALLATION The VOPEX is a Plug-and-Play device with no special configuration settings and easy installation steps: Before connecting the VOPEX to the video source, make sure the video source and the display(s) are turned OFF. 2. Connect a display to a HDMI female port labeled “HDMI Out x”... -
Page 6: Cascading
VOPEXs in a cascaded configuration (example below). Using additional HD-xx-MM cables, connect the HDMI Out ports of a master VOPEX unit (master is connected to the video source) to the HDMI In ports of additional VOPEX-HDS-x (shown as “Slave Unit #1” and “Slave Unit #2” below). -
Page 7: Technical Specifications
NTI HDMI Splitter TECHNICAL SPECIFICATIONS Video Source Device with HDMI output (DVD player, PC, Gaming Consoles, HD Cable box) Video Connections Female HDMI Bandwidth-Actual 2.25 GHz Bandwidth-Video 225 MHz Input Video Signal TMDS Video Color Format Standard (24bit); Deep color (30,36bit);RGB, 4:2:2, 4:4:4, xvycc... -
Page 8: Warranty Information
NTI HDMI Splitter WARRANTY INFORMATION The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com...
