Summary of Contents for NTI VOPEX-2KIM-A
- Page 1 NETWORK 1275 Danner Dr Tel:330-562-7070 TECHNOLOGIES Aurora, OH 44202 Fax:330-562-1999 INCORPORATED www.networktechinc.com ® VOPEX Series VOPEX PS/2 KEYBOARD, MONITOR & MOUSE SPLITTER Installation and Operation Manual MAN046 Rev 12/11/03...
-
Page 2: Warranty Information
Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202 CHANGES The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the right to make changes in the product design without reservation and without notification to its users. - Page 3 TABLE OF CONTENTS INTRODUCTION ....................................1 Available Options..................................1 MATERIALS ....................................1 Materials supplied with this kit ..............................1 Optional Materials..................................1 CONNECTING THE VOPEX TO THE CPU ..........................2 Installing the Optional Monitor(s)..............................2 Installing the Optional Mouse(Mice) ............................2 Installing the Optional Keyboard(s)............................2 MOUSE SPECIAL CONSIDERATIONS .............................3 POWER-UP SEQUENCE ................................3 POWER-DOWN SEQUENCE ..............................3 DIAGNOSTIC INFORMATION ..............................3...
- Page 4 MM indicates male-to-male connectors. Cables can be purchased from Network Technologies Inc by calling (330) 562-7070, or (800) RGB-TECH (800-742-8324), or by visiting our website at http://www.networktechinc.com. Note: Any internal building wiring must be performed by a local licensed electrician and comply with the National...
- Page 5 CONNECTING THE VOPEX TO THE CPU Turn OFF power to the CPU that will be connected to the VOPEX before connecting or disconnecting any cables. WARNING If power to the CPU is not turned OFF before connecting or disconnecting cables, damage to the CPU may result.
- Page 6 MOUSE SPECIAL CONSIDERATIONS NOTE If the VOPEX is power-cycled with the CPU ON, the mouse driver must be reloaded for mice to function properly. Hot plugging limitations Any mouse to be emulated must be connected to the first populated port at VOPEX power-up. e.g. If at a later time the user wants to hot-plug 3-button mice, a 3-button mouse must have been connected in the first position at VOPEX power- If no mice were connected at power-up, VOPEX will default to standard 2-button mode.
-
Page 7: Troubleshooting
If trouble is still being experienced, a solution may be found in the Frequently Ask Questions (FAQ’s) section of our website at http://www.networktechinc.com or please call us directly at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 and we will be happy to assist in any way we can. SERIAL NO.: VOPEX-2KIM-A PS/2 keyboard + PS/2 mouse 2 port VOPEX-2KVIM-A...
