SPLITMUX-SVDVI-2 DUAL SCREEN SPLITTER
COMMANDS
!
51 VPOSIT n m
52 HSIZE n m
53 VSIZE n m
54 SWAPIN
55 RECONFIG
56 HPOSITPIP n
57 VPOSITPIP n
58 HSIZEPIP n
59 VSIZEPIP n
60 RGBSYNC n m
61 SWAPWIN
62 POWERON
63 POWEROFF
64 MUTEON
65 MUTEOFF
66 VOLUME+
67 VOLUME-
68 VOLUME n
69 AUDIOINPUT n
69 AUDIOOUTPUT n
70 AUDIODELAY n
71 OSDTRANS n
72 PIPTRANS n
73 ADCCALIBR
74 FREEZE n
75 BRIGHTNESS n
76 CONTRAST n
77 SATURATION n
78 HUE n
79 ZOOM n m
80 CROPLEFT n m
81 CROPRIGHT n m
82 CROPTOP n m
83 CROPBOTTOM n m
84 CROPSAVE n
85 CROPRESET n
86 OSDON
87 OSDOFF
88 VERFLIPON
FUNCTION
SET V.POSITION
SET H.SIZE
SET V.SIZE
SWAP INPUTS
RECONFIGURE SPLITMUX
SET H.POS FOR PIP
SET V.POS FOR PIP
SET H.SIZE FOR PIP
SET V.SIZE FOR PIP
RGB/YPbPr TYPE
SWAP INPUT
POWER ON
POWER OFF
AUDIO MUTE ON
AUDIO MUTE OFF
VOLUME UP
VOLUME DOWN
VOLUME LEVEL
AUDIO INPUT SOURCE
AUDIO OUTPUT SOURCE
AUDIO DELAY
OSD TRANSLUCENCY
PIP TRANSLUCENCY
A/D RGB Auto Calibration
FREEZE OUTPUT IMAGES
BRIGHTNESS CONTROL
CONTRAST CONTROL
SATURATION CONTROL
HUE CONTROL
ZOOM
CROP LEFT
CROP RIGHT
CROP TOP
CROP BOTTOM
CROP SAVE
CROP RESET
OSD ON
OSD OFF
VERTICAL FLIP ON
31
NOTE
n (window):1, 2; m = 0 to 1000
n (window):1, 2; m = 0 to 1000
n (window):1, 2; m = 0 to 1000
Swap inputs from window 1 and 2
n = 0 to 1000
n = 0 to 1000
n = 0 to 1000
n = 0 to 1000
n = A; m = HV, SOG, YPRPB
Swap window 1 and 2 only (sbs, pip)
n is value in percent
n is SOUND_A, SOUND_B, SPDIF_A,
SPDIF_B
n ANALOG, SPDIF
n is value in percent
n is value in percent
n is value in percent
n is 0 for off, 1 for on
n = 0 to 1000
n = 0 to 1000
n = 0 to 1000
n = 0 to 1000
n (window): 1,2; m = 0 to 1000
n (window):1, 2; m = pixels
n (window):1, 2; m = pixels
n (window):1, 2; m = pixels
n (window):1, 2; m = pixels
n (window):1, 2
n (window):1, 2
