SPLITMUX-SVDVI-2 DUAL SCREEN SPLITTER
3
IR Remote and basic key functions
The SPLITMUX-SVDVI-2 can be controlled using an IR remote control, via the front panel, or
RS-232 commands. The remote is addressable for installing with multiple SPLITMUX units. To
change the address on the remote:
- Press and hold the 'Up' and 'Down' arrows together for 5 seconds. The red LED will
start to blink
- Enter the address (0-255) and press 'Select'
In order for the IR remote to properly control a SPLITMUX, both devices (IR remote and the
SPLITMUX) have to have the same address. See System Setup Menu (pg. 18) for more
information on how to change the SPLITMUX's address.
Up Arrow
Select
Down Arrow
5
