VOPEX-C5VA/C5V-x(C)
VOPEX-C5SVA/C5SV-x
VOPEX-C5HDTV/C5HDA-x
Installation and Operation Manual
1275 Danner Dr
Tel:330-562-7070
Fax:330-562-1999
Aurora, OH 44202
www.networktechinc.com
VOPEX
VOPEX-M12V-4
Video/Audio or Video Only
Splitter/Extender
®
Series
(Receiver not included)
MAN071 Rev Date 3/21/2012
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NTI VOPEX-C5VA/C5V-x(C)
Summary of Contents for NTI VOPEX-C5VA/C5V-x(C)
- Page 1 NETWORK 1275 Danner Dr Tel:330-562-7070 TECHNOLOGIES Fax:330-562-1999 Aurora, OH 44202 INCORPORATED www.networktechinc.com ® VOPEX Series VOPEX-C5VA/C5V-x(C) VOPEX-C5SVA/C5SV-x VOPEX-C5HDTV/C5HDA-x VOPEX-M12V-4 Video/Audio or Video Only Splitter/Extender Installation and Operation Manual (Receiver not included) MAN071 Rev Date 3/21/2012...
- Page 2 Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. CHANGES The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the right to make changes in the product design without reservation and without notification to its users.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Materials ..................................2 Features and Functions..............................3 Limitations ..................................5 Preparation for Installation .............................. 5 VOPEX Installation................................6 VOPEX-C5VA-x and VOPEX-C5V-x ........................... 6 VOPEX-C5SVA-x and VOPEX-C5SV-x ........................8 VOPEX-C5HDTV-x..............................10 VOPEX-C5HDA-x ..............................12 Receiver Installation ..............................14 ST-C5VA-R-600 and ST-C5V-R-600 Receiver ...................... -
Page 4: Introduction
NTI EXTENDEX SERIES SPLITTER/EXTENDER INTRODUCTION The VOPEX® Series Cat5 Video/Audio Splitter/Extender (VOPEX) is designed to enable one Video/Audio source to be viewed and heard in 4, 8, or 16 different remote locations. Remote video and audio devices can be located as much as 600 feet away from the source via Category 5 unshielded twisted-pair cable. -
Page 5: Materials
NTI EXTENDEX SERIES SPLITTER/EXTENDER MATERIALS Materials Included with this kit: VOPEX-C5VA-x / -C5V-x / -C5SVA-x / -C5SV-x / -C5HDTV-x / -C5HDA-x /-M12V-4 (one of these) 120VAC or 240VAC at 50 or 60Hz-9VDC/1.5A AC Adapter (not included with M12) -Or- 120VAC or 240VAC at 50 or 60Hz-5VDC/3A AC Adapter (VOPEX-C5V(A)-4C/8C models only) Line cord, country specific (not included with M12) CD with a pdf file of this manual and pdf file of a Quick Installation Guide Quick Installation Guide... -
Page 6: Features And Functions
1275 Danner Dr Tel:330-562-7070 TECHNOLOGIES Aurora, OH 44202 Fax:330-562-1999 INCORPORATED www.nti 1.com Cat5 9VDC 1.5A Line Line XTENDEX Video Network Technologies Inc Adjust Power (Front View) (Rear View) S-Vout S-Vin VOPEX-C5VA-8 (S-Video connectors on VOPEX-C5SVA-8) INPUT LOCAL OUTPUT INPUT LOCAL OUTPUT... - Page 7 14b. Stereo Audio Connectors-RCA- connection for right and left channel stereo audio amplifier 14c. Digital Audio Connector-RCA- connection for digital audio device 15. 9VDC 1.0A- connection jack for 9VDC 1A AC adapter Network Technologies Inc XTENDEX (S-video Connector of ST-C5SVA-R-600)
-
Page 8: Limitations
NTI EXTENDEX SERIES SPLITTER/EXTENDER LIMITATIONS • The audio input of the VOPEX-C5VA is compatible with the following standard CPU audio outputs: • Line out - typically lime green in color • Speaker out- typically orange in color • Headphone out- typically located on the CD-ROM •... -
Page 9: Vopex Installation
NTI EXTENDEX SERIES SPLITTER/EXTENDER VOPEX INSTALLATION VOPEX-C5VA-x and VOPEX-C5V-x Note: VOPEX-C5V-x Video Only Splitter/Extender does not have audio support. If the audio support is not present, please disregard all audio references. 1. Make connections between the VOPEX-C5VA-x and the audio and video source(s). (See Fig. 1.) Connect the male15HD cable end of a VEXT-3 to the VGA connector on the back of the video source. -
Page 10: Figure 2- Connect Local User Components And Cat5 Cable To Vopex-C5Va-8
NTI EXTENDEX SERIES SPLITTER/EXTENDER Connect the local user to the VOPEX-C5VA-x (see Fig. 2) Connect the cable from the local user's VGA monitor to the 15HD female connector marked "Monitor" on the VOPEX-C5VA-x. Connect the cable from the local speakers into the 3.5mm stereo audio connector marked "Line Out"... -
Page 11: Vopex-C5Sva-X And Vopex-C5Sv-X
NTI EXTENDEX SERIES SPLITTER/EXTENDER VOPEX-C5SVA-x and VOPEX-C5SV-x Note: VOPEX-C5SV-x S-Video Only Splitter/Extender does not have audio support. If the audio support is not present, please disregard all audio references. 1. Make connections between the VOPEX-C5SVA-x and the audio and video source(s). (See Fig. 3) Connect a 4-pin miniDIN cable end of a SVEXT-3-MM to the VGA connector on the back of the video source. -
Page 12: Figure 4- Connect Local User Components And Cat5 Cable To Vopex-C5Sva-8
NTI EXTENDEX SERIES SPLITTER/EXTENDER Connect the local user to the VOPEX-C5SVA-x (see Fig. 4) a. Connect one end of another SVEXT-xx-MM cable to the 4-pin miniDIN female connector marked "S-Vout" on the VOPEX-C5SVA-x. b. Connect the other end of the SVEXT-xx-MM cable to the 4-pin miniDIN female connector on the local s-video display. -
Page 13: Vopex-C5Hdtv-X
NTI EXTENDEX SERIES SPLITTER/EXTENDER VOPEX-C5HDTV-x Make connections between the VOPEX-C5HDTV-x and the stereo audio and HD video source. (See Fig. 5.) Connect the video ends of the CMPSAEXT-1.5-MM RCA coax cable (supplied) to the HD video source. Connect the video ends on the other end of the CMPSAEXT-1.5-MM RCA coax cable to connectors marked "INPUT"... -
Page 14: Figure 6- Connect Local Hdtv And Stereo Speakers
NTI EXTENDEX SERIES SPLITTER/EXTENDER VOPEX-C5HDTV-8 (Rear View) INPUT LOCAL OUTPUT Cat5 9VDC 1.5A NETWORK TECHNOLOGIES INCORPORATED 1275 Danner Dr Tel:330-562-7070 Aurora, OH 44202 Fax:330-562-1999 www.nti1.com 75 ohm RCA cables stereo audio cable Self-Powered Amplifier CAT5 Cable to ST-C5HDTV-R-600 Receiver HDTV Stereo Speakers Locally connected devices... -
Page 15: Vopex-C5Hda-X
NTI EXTENDEX SERIES SPLITTER/EXTENDER VOPEX-C5HDA-x Make connections between the VOPEX-C5HDA-x and the digital audio and HD video source. (See Fig. 7.) Connect a set of 75 ohm RCA cables to the HD video source. Connect the other end of the RCA coax cables to connectors marked "INPUT" on the VOPEX- C5HDA-x. -
Page 16: Figure 8- Connect Hdtv And Digital Audio Devices
NTI EXTENDEX SERIES SPLITTER/EXTENDER VOPEX-C5HDA-8 (Rear View) INPUT LOCAL OUTPUT Digital Digital Cat5 9VDC 1.5A NETWORK TECHNOLOGIES INCORPORATED 1275 Danner Dr Tel:330-562-7070 Aurora, OH 44202 Fax:330-562-1999 www.nti1.com 75 ohm RCA cables coax cable for digital audio CAT5 Cable to ST-C5HDA-R-600 Receiver Digital Audio Receiver... -
Page 17: Receiver Installation
Fig. 9). ST-C5VA-R-600 Receiver (Front and Rear View) Front View of Receiver Rear View of Receiver 15HD Female Video Connector Network Technologies Inc XTENDEX CAT5 Cable to VOPEX-C5VA-x Multi-Scan Monitor Remote User's Monitor and Speakers Figure 9- Connect the Extended Components to the ST-C5VA-R-600 Receiver Make sure the CAT5 cable has been installed in accordance with the “Preparation for... -
Page 18: St-C5Sva-R-600 And St-C5Sv-R-600 Receiver
4. Connect the remote user's speakers to the 3.5mm female stereo connector on the Receiver (see Fig. 10). ST-C5SVA-R-600 Receiver (Front and Rear View) Front View of Receiver Rear View of Receiver Network Technologies Inc XTENDEX SVEXT-xx-MM CAT5 Cable to S-Video VOPEX-C5SVA-x... -
Page 19: St-C5Hdtv-R-600 And St-C5Hda-600 Receiver
Connect coax cable for digital audio (ST-C5HDA-600 only) or stereo audio cable (ST-C5HDTV-600 only) between the audio connection(s) on the Receiver and the audio device. (See Fig. 11) ST-C5HDA-600 Receiver ST-C5HDTV-600 Receiver Network Technologies Inc Network Technologies Inc XTENDEX XTENDEX... -
Page 20: Plug-In And Boot Up
NTI EXTENDEX SERIES SPLITTER/EXTENDER PLUG-IN AND BOOT UP Plug the power cord from each video device and the power supply for each audio device into a power outlet. 1.5A Connect the 9VDC AC adapter (or 5VDC 3A, see product markings) power connector to the power port on the VOPEX. -
Page 21: Installation For Vopex-M12V-4 And St-M12V-4
NTI EXTENDEX SERIES SPLITTER/EXTENDER INSTALLATION FOR VOPEX-M12V-4 AND ST-M12V-4 Installation of the VOPEX splitter and receivers with M12 connectors is the same as those with RJ45 connectors, except that M12 male connectors must be applied to the ends of the CAT5 cables. See the images below for the required connections and proper wiring pinout of the male M12 connector (wired to EIA/TIA 568B standard). -
Page 22: Video Quality Adjustment
Note: Video quality adjustment of the VOPEX-C5V-x or VOPEX-C5SV-x is performed manually at the Receiver. See "Video Quality Adjustment for VOPEX-C5V-x / -C5SV-x" below. VOPEX-C5VA-x (Front View) XTENDEX Video Network Technologies Inc Adjust Power Press button inside using non-conductive (i.e. wood or plastic) pointed object to... -
Page 23: Technical Specifications
NTI EXTENDEX SERIES SPLITTER/EXTENDER TECHNICAL SPECIFICATIONS VOPEX-C5VA / -C5V Models Maximum Resolution See chart next page Video Compatibility SVGA, XGA, VGA Video Connectors HD15 female for monitor connection HD15 male for CPU video connection VOPEX-C5SVA / -C5SV Models Maximum Resolution 800 x 600 - up to 600 feet (refresh frequency 60Hz) Video Compatibility... - Page 24 NTI EXTENDEX SERIES SPLITTER/EXTENDER General (All Above Models) Interconnect Cable CAT5/5e Solid UTP EIA/TIA 568B wiring w/ male RJ45 connectors VOPEX-C5 Power 120V or 240V at 50 or 60Hz-9VDC/1.5A via AC Adapter VOPEX-C5V(A)-4/8C Power 120V or 240V at 50 or 60Hz-5VDC/3A via AC Adapter Receiver Power 120V or 240V at 50 or 60Hz-9VDC/1.0A via AC Adapter AC Adapter Power Connector...
-
Page 25: Interconnection Cable Wiring Method
NTI EXTENDEX SERIES SPLITTER/EXTENDER INTERCONNECTION CABLE WIRING METHOD The connection cable between the VOPEX and each XTENDEX Receiver is terminated with either RJ45 connectors or M12 connectors (see installation instruction for you model) and must be wired according to the EIA/TIA 568B industry standard. Wiring is as per the tables and drawings below. -
Page 26: Troubleshooting
NTI EXTENDEX SERIES SPLITTER/EXTENDER TROUBLESHOOTING Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise. -
Page 27: Warranty Information
NTI EXTENDEX SERIES SPLITTER/EXTENDER WARRANTY INFORMATION The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com for information regarding repairs and/or returns.
