Summary of Contents for NTI VOPEX-C5VA-xC1000
- Page 1 ® VOPEX Series VOPEX-C5VA-xC1000 Video/Audio Splitter/Extender Installation and Operation Manual (Receiver not included) MAN186 Rev Date 12/13/2012...
- Page 2 Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. CHANGES The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the right to make changes in the product design without reservation and without notification to its users.
-
Page 3: Table Of Contents
Features and Functions..............................2 Limitations ..................................3 Preparation for Installation .............................. 3 VOPEX Installation................................4 VOPEX-C5VA-xC1000 ..............................4 Remote Unit Installation ..............................6 ST-C5V2A-R-1000SP and ST-C5V-R-1000SP Remote Unit..................6 ST-C5VA-R-600 and ST-C5V-R-600 Remote Unit ..................... 7 Connect the CAT5 cable.............................. 8 Plug-in and Boot Up ................................ -
Page 4: Introduction
4 or 8 different remote locations. Remote video and audio devices can be located as much as 1000 feet away from the source via Category 5 unshielded twisted-pair cable. The VOPEX-C5VA-xC1000 (x=4 or 8 port) also allows a local video and audio device to be located near the source. -
Page 5: Features And Functions
NTI VOPEX SERIES SPLITTER/EXTENDER FEATURES AND FUNCTIONS VOPEX LABEL CONNECTOR/LED DESCRIPTION 5V 3.0A 1.3x3.5mm Power Jack connection jack for 5VDC AC adapter Green LED illuminates when power has been supplied to the VOPEX DDC Update Gray Button Press to transfer updated EDID data from remote units to CPU Ground Crimp Terminals For attachment of earth ground to VOPEX... -
Page 6: Limitations
NTI VOPEX SERIES SPLITTER/EXTENDER LIMITATIONS • The audio input of the VOPEX-C5VA-xC1000 is compatible with the following standard CPU audio outputs: • Line out - typically lime green in color • Speaker out- typically orange in color • Headphone out •... -
Page 7: Vopex Installation
1000 foot Remote Units that are connected, but may not work on the 600 foot Remote Units (depending upon the features available at the time of manufacture). VOPEX-C5VA-xC1000 1. Make connections between the VOPEX and the audio and video source(s). (See Fig. 1.) Connect the male15HD cable end of a VEXT-3 to the VGA connector on the back of the video source. - Page 8 NTI VOPEX SERIES SPLITTER/EXTENDER Connect the local user to the VOPEX. Connect the cable from the local user's VGA monitor to the 15HD female connector marked "Monitor" on the VOPEX. Connect the cable from the local speakers into the 3.5mm stereo audio connector marked "Audio Out"...
-
Page 9: Remote Unit Installation
NTI VOPEX SERIES SPLITTER/EXTENDER REMOTE UNIT INSTALLATION ST-C5V2A-R-1000SP and ST-C5V-R-1000SP Remote Unit 1. Position the Remote Unit such that the CAT5 cable, the monitor cable, device cables, and the AC adapter power connector can each reach the Remote Unit without putting strain on the cables. 2. -
Page 10: St-C5Va-R-600 And St-C5V-R-600 Remote Unit
NTI VOPEX SERIES SPLITTER/EXTENDER ST-C5VA-R-600 and ST-C5V-R-600 Remote Unit Note: This section is applicable to both models of Remote Unit except for step 3. When installing ST-C5V-R-600 Remote Units (no audio support), disregard step 3. Position a ST-C5VA-R-600 Remote Unit such that the CAT5 cable, the monitor cable, speaker cable, and the AC adapter power connector can each reach the Remote Unit comfortably. -
Page 11: Connect The Cat5 Cable
NTI VOPEX SERIES SPLITTER/EXTENDER Connect the CAT5 cable Make sure the CAT5 cable has been installed in accordance with the “Preparation for Installation” instructions on page 3. Connect the CAT5 cable to the “Cat 5” port on each Remote Unit. (See Fig. 4) When properly inserted the CAT5 cable end should snap into place. -
Page 12: Plug-In And Boot Up
NTI VOPEX SERIES SPLITTER/EXTENDER PLUG-IN AND BOOT UP Plug the power cord from each video device and the power supply for each audio device into a power outlet. Connect the 5VDC 3A power connector to the power port on the VOPEX (shown in Fig. 1- Page 5). Connect a 9VDC AC adapter to each XTENDEX Remote Unit. -
Page 13: Video Quality Adjustment
VOPEX-C5VA-xC1000 When powering ON the VOPEX-C5VA-xC1000, video quality adjustment is done automatically to assure the image is as clear as possible. Once the VOPEX is up and running, an adjustment may need to be made to the resolution setting of the CPU, due to variations in compatible resolutions in the monitors connected to the Remote Units. -
Page 14: Figure 7- Video Adjustment Buttons
NTI VOPEX SERIES SPLITTER/EXTENDER Depending upon what mode the XTENDEX is in, the “+” (plus) and “-“ (minus) buttons can be pressed to make the adjustment. A “Mode” LED is provided to indicate what characteristic is being changed. Figure 7- Video Adjustment buttons Note: The VOPEX and Remote Units must be connected and communicating in order for the mode button to function. -
Page 15: St-C5V-R-600 Video-Only Extenders
NTI VOPEX SERIES SPLITTER/EXTENDER ST-C5V(X2)-R-600 Video-Only Extenders Video quality adjustment of the monitor connected to an ST-C5V-R-600 Remote Unit or ST-C5VX2-R-600 is performed manually at the Remote Unit. It is possible that on initial startup the image on the monitor will not be as crisp as the image normally is. This is due to the frequency characteristics of the CAT5 cable. -
Page 16: Technical Specifications
NTI VOPEX SERIES SPLITTER/EXTENDER TECHNICAL SPECIFICATIONS Characteristic With 600 Foot XTENDEX Remote Units With 1000 Foot XTENDEX Remote Connected Units Connected Video Compatibility SVGA, XGA, VGA VGA,SVGA, XGA, SXGA,UXGA Video Quality Adjustment Automatic, for up to 600 feet of CAT5 Automatic, for up to 1000 feet of CAT5 cable, with manual override cable, with manual override... -
Page 17: Interconnection Cable Wiring Method
NTI VOPEX SERIES SPLITTER/EXTENDER ST-C5VA-R-600 Remote Units Distances and Maximum Supported Resolutions for CAT5, CAT5e and CAT6 Cables CABLE DISTANCE (feet) RESOLUTION CAT5/CAT5e (UTP) 1024x768 at 60Hz CAT5/CAT5e (UTP) 1280x1024 at 60Hz CAT5/CAT5e (UTP) 1600x1200 at 60Hz CAT5/CAT5e (UTP) 1920x1440 at 60Hz CAT6 (UTP) 1024x768 at 60Hz CAT6 (UTP) -
Page 18: Troubleshooting
NTI VOPEX SERIES SPLITTER/EXTENDER TROUBLESHOOTING Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise.
