SPLITMUX-SVDVI-2 DUAL SCREEN SPLITTER

13 Specifications

a. Supported Video Timing
Input Format
525/60 NTSC, ITU-R
BT601-5, RS-170M
525/60 NTSC, CCIR
656
625/50 PAL/SECAM,
ITU-R BT601-5
625/50 PAL/SECAM,
CCIR 656
480p 4:3, SMPTE
293M
720p, SMPTE 296M
74.25/1.001
1080i, SMPTE 274M
74.25/1.001
1080p, SMPTE
74.25/1.001
Note: SPLITMUX will accept interlaced signals but will not output interlaced signals. Interlaced
inputs will be de-interlaced and displayed as a high quality progressive signal.
Supported Default DVI/RGB PC Graphics Input & Output Timing
Mode Resolution
VGA 640x480 @ 60 Hz 800x525
VGA 640x480 @ 72 Hz 832x520
VGA 640x480 @ 75 Hz 840x500
WVGA 852x480 @ 60Hz 1072x529
SVGA 800x600 @ 60 Hz 1056x628
SVGA 800x600 @ 72 Hz 1040x666
SVGA 800x600 @ 75 Hz 1056x625
XGA 1024x768 @ 60 Hz 1344x806
XGA 1024x768 @ 70 Hz 1328x806
XGA 1024x768 @ 75 Hz 1312x800
XGA 1024x768 @ 85 Hz 1376x808
WXGA 1280x768 @ 60 Hz 1688x802
SXGA 1280x1024 @ 60 Hz 1688x1066
SXGA 1280x1024 @ 75 Hz 1688x1066
SXGA 1280x1024 @ 85 Hz 1728x1072
UXGA 1600x1200 @ 60 Hz 2160x1250
Note: SPLITMUX has the ability to program additional resolutions in User profiles. This can be
found in the Signal Timing OSD section.
Horiz. Freq. Vertical Freq.
(KHz) (Hz)
15.75/1.001 60.0/1.001
15.75/1.001 60.0/1.001
15.625 50.000
15.625 50.000
31.5/1.001 60.0/1.001
45.0/1.001 60.0/1.001
33.750/1.001 60.0/1.001
67.4 60.0/1.001
Active
Resolution
720x480 @ 59.94i
720x480 @ 59.94p
720x576 @ 50.00i
720x576 @ 50.00i
720x483 @ 59.94p
1280x720 @ 59.94p
1920x1080 @ 59.94i
1920x1080 @ 59.94p
Horizontal Vertical
Frequency Frequency
31.469 59.940
37.861 72.809
37.500 75.000
31.700 60.000
37.879 60.317
48.077 72.188
46.875 75.000
48.363 60.004
56.476 70.069
60.023 75.029
68.600 85.000
48.134 60.017
63.900 60.000
79.900 75.000
91.100 85.000
76.900 60.000
34
Total Pixel Clock
Resolution (MHz)
858x525 13.500
858x525 27.000
864x625 13.500
864x625 27.000
858x525 27.000
1650x750
2200x1125
2200x1125
Pixel Clock (Mhz)
25.175
40.000
65.000
81.25
