SPLITMUX-SVDVI-2 DUAL SCREEN SPLITTER
7

Operating the SPLITMUX-SVDVI-2

The SPLITMUX-SVDVI-2 has many advanced features to enhance the typical viewing
experience. A user can switch the unit on or off, control volume level, switch the current source,
rotate an image, and many other functions.
Advanced functionalities may differ in some of the operating modes, which will be described in
more detail and in the subsequent chapters of this document.

7.1 Remote Control Functions

Key Description
Vol+/-
Increases or decreases the volume level
0-9
Used for direct number entry for menu items such as presets, zoom, size, position,
etc.
Menu
Displays the Main Menu (pg. 12).
Sel
Enters selections / confirms changes in the menu
Exit
Exits one level in the menu or turns OFF OSD that's being displayed.
Power
Toggles the power ON/OFF
Rotate
Rotates output image by 0, 90, 180, and 270 degrees
Swap
Swaps input sources between window 1 and window 2 when the SPLITMUX is in PiP
or SBS mode
Info Displays current sources, input / output timing information, and FW version via OSD. This
information will be displayed for 5 seconds
Freeze
When pressed, it stills the current image on the screen. Pressing again will resume
motion
Zoom,
When pressed, it will bring up a menu to select the window to be adjusted. All these
Crop,
selections have a range of 0-100 percent with tenths of a percent accuracy for a total
Pos, of 1000 points of precision adjusting.
Size
•
Zoom: enlarges or shrinks the output image.
•
Crop: is specific to an input and is used when under scanning an image to
•
Size: is used to separately adjust of the horizontal and vertical size of an
•
Position: moves the window up/down or left/right. Position will only work if
Single,
These keys select picture layout (how many windows will be displayed) of the output.
•
Dual,
Single: only one picture is displayed on the output.
•
Tri,
Dual: toggles between PiP and SBS. When in PiP mode, translucency can
Quad
be adjusted using Up/Down arrows (no menus are present).
•
Tri: Not available for SPLITMUX-SVDVI-2
•
Quad: Not available for SPLITMUX-SVDVI-2
remove unwanted areas around the border. It helps balance the inputs
with each other.
output image.
the image is zoomed.
