- Page 1 VOPEX-C6HD-8LC 1 by 8 HDMI to single CAT6 Splitter Operation Manual...
-
Page 2: Revision History
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 3: Table Of Contents
Table of Contents Introduction ……………………..……………………...…..….……. Applications …………………..………………….……....….. Package Contents ………………………...………....… System Requirements ……………..………..………....……. Features …………………………………………..……..…...…… Specifications ………………………………...……..………..…. Operation Controls and Functions ……………...……....…… Front Panel ................Rear Panel .…………………………………..……..…...….… Connection and Installation ….…………………..…..…..…..Acronyms ….................. -
Page 4: Introduction
1. Introduction This 1 by 8 HDMI v1.3 to single CAT6 Splitter can simultaneously distribute a single HDMI source to eight displays when connecting with a CAT6 to HDMI receiver. Providing you with an efficient and cost effective way to link your displays, this system uses a direct input of one HDMI source and eight CAT6 outputs that send uncompressed data and allow you to distribute HDMI signals at their full strength and at great distances. -
Page 5: Features
5. Features HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant Deep color video input up to 12 bits, 1080p@60Hz Deep color video output up to 10 bits, 1080p@60Hz One HDMI source to eight CAT6 output allows users to simultaneously link ... -
Page 6: Specifications
6. Specifications TMDS Clock Frequency 225Mbps Input Port 1 x HDMI Output Port 8 x Single CAT6 EDID STD/TV HDMI Audio Output PCM2, 5.1, 7.1, Dolby 5.1 DTS 5.1, DD+, D-TrueHD, DTS-HD HDMI Cable In 1080p 8-bit (10M), 12-bit (10M) CAT6 Cable Out 1080p 8-bit (45M), 10-bit (15M) HDMI Resolution... -
Page 7: Operation Controls And Functions
7. Operation Controls and Functions The following sections describe the hardware components of the unit. 7.1 Front Panel CLUX-8MCAT POWER 1 x 8 HDMI SYNC-RED OVER CAT6 SPLITTER CAT6 OUT CAT6 OUT 3D-ORG HDMI IN CAT6 OUT DC 5V ① ②... - Page 8 3. The EDID selection will only be activated when the unit is plugged in and powered on. ② CAT6 OUT 2~6: These slots are to connect with the displays through single CAT6 to HDMI receiver with connection cables. Note: A. This system was tested with CAT-6E/23AWG cables, so if using cables of another type, the performance of this system may be different.
-
Page 9: Connection And Installation
8. Connection and Installation Blu-Ray CH-107RX CH-107RX CH-107RX CH-107RX CH-107RX TV / Monitor TV / Monitor TV / Monitor TV / Monitor TV / Monitor... -
Page 10: Acronyms
Acronyms Acronym Complete Term 3 Dimension CAT6 Cable Category 6 cable Digital Visual Interface EDID Extended Display Identification Data HDCP High-bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface...
