Summary of Contents for NTI Vopex-2V
- Page 1 ® VOPEX Series VOPEX-2V/4V/8V/16V-H VOPEX-2VA/4VA/8VA-H VIDEO AND AUDIO/VIDEO SPLITTER Installation and Operation Manual MAN003 Rev 7/11/07...
- Page 2 TRADEMARK VOPEX is a registered trademark of Network Technologies Inc in the U.S. and other countries. COPYRIGHT Copyright 2003, 2007 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, OH 44202.
-
Page 3: Materials Supplied
INTRODUCTION The VOPEX-2V/4V/8V/16V-H video port splitter enables two, four, eight, or sixteen monitors to be driven from the same video port. These units have a bandwidth of 150 MHz enabling them to support high resolution video – up to 1900x1200 with no •... -
Page 4: Installation
DDC monitor connected to OUTPUT-1. Install the 15HD male end of the NTI-supplied video interface cable into the CPU’s video output connector. Install the 15HD female end of this cable into the INPUT connector of the VOPEX. -
Page 5: Audio Support
AUDIO SUPPORT Models with audio support (i.e. VOPEX-2VA-H) can additionally be connected to an audio source. A 3.5mm jack is provided for connection to the audio source using the 3 foot audio cable (provided). Outputs are provided for connection of self-powered stereo speakers, headphones, and/or ear buds. - Page 6 CASCADING Up to 100 monitors can be driven using a single CPU by cascading multiple VOPEX splitters as shown in Fig. 2. Other than additional VOPEX splitters, the only additional hardware required are VEXT-THN-xx cables with lengths sufficient to reach each of the monitors to be connected and for connecting the VOPEX splitters.
- Page 7 Self-powered Existing Cable Stereo Speakers AUDIO OUT AUDIO IN AUDIO OUT AUDIO IN NETWORK TECHNOLOGIES INC 1275 Danner Dr, Aurora, OH 44202 Tel:330-562-7070 www.networktechinc.com NETWORK TECHNOLOGIES INC 1275 Danner Dr, Aurora, OH 44202 Tel:330-562-7070 www.networktechinc.com REAR VIEW OF VOPEX-8VA-H REAR VIEW OF VOPEX-8VA-H SLAVE #2 SA-xx-MM SLAVE #1...
-
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS VIDEO INPUT/OUTPUT SIGNALS PIN # SIGNAL PIN # SIGNAL GREEN BLUE DDC DAT DDC CLK Mating Face of a 15HD Male 3.5mm Stereo Jack (side view) RING (RIGHT) (FRONT) TIP (LEFT) SLEEVE (GND) VIdeo Output Connectors 15HD female Input Connector 15HD male Compatibility... -
Page 9: Troubleshooting
Technologies Inc at (800) 742-8324 (800-RGB-TECH) in the U.S. and Canada or 330-562-7070 (worldwide) for information regarding repairs and/or returns. A return authorization number is required for all repairs/returns. SERIAL NO: ______________________ DATE: ______________________ INSPECTED BY: _____________________ VOPEX-2V-H VOPEX-2VA-H VOPEX-4V-H VOPEX-4VA-H VOPEX-8V-H...
