SPLITMUX-SVDVI-2 DUAL SCREEN SPLITTER
COMMANDS
!
11 KEY_NUM6
12 KEY_NUM7
13 KEY_NUM8
14 KEY_NUM9
15 KEY_LEFT
16 KEY_RIGHT
17 KEY_UP
18 KEY_DOWN
19 KEY_SEL
20 KEY_MENU
21 KEY_EXIT
22 KEY_POWER
23 KEY_MUTE
24 KEY_INFO
25 KEY_ROTATE
26 KEY_ZOOM
27 KEY_CROP
28 KEY_POS
29 KEY_SIZE
30 KEY_A_DVI
31 KEY_A_RGB
32 KEY_A_VIDEO
33 KEY_B_DVI
34 KEY_B_RGB
35 KEY_B_VIDEO
36 KEY_SINGLE
37 KEY_DUAL
38 KEY_TRI
39 KEY_QUAD
40 KEY_FREEZE
41 KEY_SWAP
42 SETDEFAULT
43 PRESET n
44 S_PRESET n
45 RSADDR n
46 WINDOW n m
47 ROTATE n
48 LAYOUT m
49 OUTFORMAT n
50 HPOSIT n m
FUNCTION
NUMBER 6
NUMBER 7
NUMBER 8
NUMBER 9
LEFT ARROW
RIGHT ARROW
UP ARROW
DOWN ARROW
SELECT
MENU
EXIT
POWER TOGGLE
AUDIO MUTE
INFORMATION
ROTATE
ZOOM
CROP
POSITION
SIZE
DVI INPUT
RGB INPUT
VIDEO/SVIDEO INPUT
Not Available
Not Available
Not Available
SINGLE MODE
DUAL MODE
Not Available
Not Available
FREEZE
SWAP WINDOW SOURCES
FACTORY DEFAULTS
RECALL PRESET
STORE PRESET
SET ADDRESS
SELECT WINDOW
ROTATE OUTPUT
SET LAYOUT
OUTPUT RESOLUTION
SET H. POSITION
30
NOTE
n = 00 to 99
n = 00 to 99
n = 000 to 254 (255 or ***: Broadcast)
n = 1, 2; m: input*
Degree of rotation: 90*(n); n = 0, 1, 2, 3
m = single, dual, pip, sbs
n = output resolution**
n (window):1, 2; m = 0 to 1000
