SPLITMUX-SVDVI-2 DUAL SCREEN SPLITTER

11 Troubleshooting

Symptom
Key on remote is pressed but
nothing happens
The display does not turn on or
show an image
No control via RS-232
connection to SPLITMUX
DVI output has horizontal noise
going across intermittently
Video is black and white
S-Video does not lock
DVI has output but RGB does
not
No image on either output
Image is green on the input
Image is green on the output
Tri Mode does not work
Quad Mode does not work
Side B input keys do not work
Check to see if the batteries are good. If the batteries are
good – check the cable connections between the Plasma
Display and the SPLITMUX Also, make certain the
SPLITMUX has power.
Check if the IR remote address is the same as the
SPLITMUX's address in System Setup menu.
Check to see if the OSD from the SPLITMUX displays. If it
does check the source selection and/or cables for the
source. If there is no OSD then make certain the output
cable is connected properly and the output timing of the
SPLITMUX matches the capabilities of the display device.
Make sure the SPLITMUX is not in standby.
Check cable connection. If connection is ok, check baud
rate and address of SPLITMUX
This could happen if a DVI cable is too long. Typical DVI
should not exceed 6ft. Some after market products can
enhance the length of DVI. Double check the specifications
before using these types of DVI cables.
Under Input Settings, check the selection for the SVID. If
the video sync is weak try using video selection instead of
Auto. Also, make certain it is not set for S-Video.
Under Input Settings check the selection for the SVID.
Make certain the selection is not set for Video.
If the content has HDCP, the RGB/YPbPr output will be
disabled due to copyright protection. If it is not HDCP
protected, check the Output Setup to make certain RGB is
not disabled.
Check output resolution is compatible with display device
and the SPLITMUX is not in standby mode.
Make certain the SPLITMUX input for RGB/YPbPr is set up
correctly.
If the output of the SPLITMUX is setup incorrectly (RGBHV
vs YPbPr vs RGsB) it may result in a green image.
SPLITMUX does not have this feature.
SPLITMUX does not have this feature.
SPLITMUX does not have the additional inputs.
