SPLITMUX-SVDVI-2 DUAL SCREEN SPLITTER
COMMANDS
?
17 HUE
18 ZOOM n
19 INFO
20 CROPLEFT n
21 CROPRIGHT n
22 CROPTOP n
23 CROPBOTTOM n
24 FLIP
25 STACK
Info Query:
Below is a typical response from an Info query. The information line starts with # followed by
the information. This structure and text will change based on the amount of windows displayed
and the type of sources and resolutions supplied.
# Window: 1
# Input : DVI_B, SXGA 60Hz, 1280x1024
# Window: 2
# Input : RGB+HV, no signal
# Mode : SbS
# Rotate: No
# Output: XGA 60Hz, 1024x768, DVI/RGB+HV,
# SPLITMUX address : 0
# Version: 1.11, Rev: 8649, Date: 29-Aug-2005
General Info:
After each command you need to wait for the following answer "~<ADDR> OK <string><CR>"
before sending the next RS-232 command. Some commands require time to carry out the
function assigned. If another command is sent before the SPLITMUX can complete the first
task it may ignore the next function. Always allow the SPLITMUX the proper time to finish the
command. Commands which take the longest would be Preset Load and Save and Source
changes.
Invalid commands will reply with ~ERROR<CR> as long as the address is zero.
Convert the multi-digit ASCII decimal representation response to a true hexadecimal value. Ex.
xx = 13 (0x31, 0x33) turn this into 0D. The bit information is once the ASCII to hexadecimal
conversion has been done.
FUNCTION
HUE
ZOOM
INFORMATION
CROP LEFT PIXELS
CROP RIGHT PIXELS
CROP TOP PIXELS
CROP BOTTOM PIXELS
FLIP MODE
STACK MODE
NOTE
n (window): 1,2
See below for detailed response info
n (window): 1,2
n (window): 1,2
n (window): 1,2
n (window): 1,2
