Web page features and layout

This section describes the features that can be found on some or all of the web interface pages.
The elements included in the example web pages shown here are described in the table below.
Page Description
element
Page name Every page shows the page name and the menu path to that page. Each part of
and the menu path is a link; clicking on any of the higher level menu items takes you
location to that page.
System This icon appears on the top right corner of every page when there is a system
warning warning in place. Click on this icon to go to the Warnings page which gives
information about the warning and its suggested resolution.
Help This icon appears on the top right corner of every page. Clicking on this icon
opens a new browser window with help specific to the page you are viewing. It
gives an overview of the purpose of the page, and introduces any concepts
configured from the page.
Log out This icon appears on the top right corner of every page. Clicking on this icon
ends your administrator session.
Field level An information box appears on the configuration pages whenever you either
information click on the Information icon or click inside a field. This box gives you
information about the particular field, including where applicable the valid ranges
and default value. To close the information box, click on the X at its top right
corner.
Cisco VCS Administrator Guide (X6.1)
About the Cisco TelePresence Video Communication Server (VCS)
Page 22 of 401
