Slave LinkCard(s) – If you are installing a slave LinkCard, set DIP Switches
1 and 4 to "on" and all others to "off" for one slave LinkCard. For the second
and third slaves refer to Table 1.3.
Table 1.2: Slave LinkCard Switch Settings
Switch
1
Slave 1
ON
Slave 2
ON
Slave 3 ON

LinkCard(s) Installation

1. Remove the cover of your computer as outlined in your computer's user
manual.
2. Locate an unused full length 16-bit ISA card connector (slot). Remove the
screw that holds the metal filler bracket covering the opening to the rear panel
for the selected slot. Set the screw aside, you will need it for the LinkCard.
3. Insert the card-edge of the LinkCard firmly into a full length 16-bit expansion-
slot connector on the motherboard or riser board as explained in your
computer's user manual.
4. When the LinkCard has been firmly seated in the expansion slot and the metal
bracket is aligned with the surrounding brackets, secure the LinkCard's metal
bracket with the screw you removed in step 2.
5. Repeat this procedure for additional LinkCards.
Note: if you have more than one LinkCard, attempt to install the cards side by side
in sequential slots (for convenience of troubleshooting).
Base Address
2 3 4
OFF OFF ON
OFF ON OFF
ON OFF OFF
Not Used
5 6 7
OFF OFF OFF
OFF OFF OFF
OFF OFF OFF
