Viewing Code Versions

Use the following keys in the ROTATING GOBO group (Figure A.10) with the hot key to
view the boot code, flash ROM, and 8031 EPROM code versions:
• < > displays the version number of the boot code in the Console's flash ROM. The
A
number is displayed as three digits,
LED's < > through <
A
Color LED's E through 12. And the value for z will be displayed in Gobo LED's A
through 6. The value associated with each LED is 0 through 9, reading left to right.
Note: the flash ROM and boot codes can also be read using the
drop-down menu. Refer to "Determining Software and Code Versions" on
Help
page A-4.
Example: version 2.53 would be displayed as <
COLOR group and <
• < > displays the version number of the system code in the flash ROM. The number is
B
displayed in the same manner as explained above.
• < > displays the version number of the 8031 EPROM. The number is displayed in the
C
same manner as explained above.
. The value for x will be displayed by the
x.yz
> in the COLOR group. The value for y will be displayed in
6
D > the GOBO group.
Figure A.10 ROTATING GOBO Group
About
C > in the COLOR group, <
Appendix A Installation Troubleshooting A-19
