Use this section to correctly configure and control the certain features for
Vari-Lite fixtures.

VL5 and VL5a

VL5 and VL5a fixtures do not provide the ability for internal dimming, thus an
external dimmer is required. Status Cue allows the VL5's
patched separately from other fixture Constructs. This is useful for patching all
channels in numeric order or allowing all
Dim
separate Link.
Note: VL5's Dim and other channels must be kept on the same LinkCard, but not
necessarily on the same Link.
Example:
After adding VL5 fixtures, select the
(Figure C.10.). Then patch the
Figure C.10. Selecting VL5 Dim Channels
channels to be placed on a
Dim
channels and click the
Dim
channels to the desired Link.
Dim
Appendix C Special Configuration and Control of Fixtures C-17
Construct to be
Dim
button
Patch
