Fixture Groups

Fixture Groups (groups of commonly assigned fixtures) make selecting fixtures easy.
Examples of Fixtures Groups are:
• all Cyberlights
• all Studio Colors
• all upstage fixtures
• only odd fixtures
Status Cue has the ability to store 128 Fixture Groups. Fixture Groups are stored in
four banks of 32 System Keys. Fixture Groups can be used with any Scene or
Sequence in a Show.

Changing Banks

Fixture Groups and Palettes are accessed through four Banks of 32 System keys.
The current Fixture Group and Palette Banks are indicated in the upper middle
portion of Scene and Sequence Windows below the title bar. Refer to Figure 5.45.
The following banks contain the corresponding numbers:
•
•
•
•
To change the current Bank, complete the following procedure:
5-42 Status Cue User's Manual
Figure 5.45. Fixture and Palette Bank Indicators
Bank 1- 1–32
Bank 2- 33–64
Bank 3- 65–97
Bank 4- 98–128
1. Press the desired key in the FUNCTION group (<
< PALETTE >).
2. Press the < BANK > key in the CONTROL group (Figure 5.46). This brings
up the corresponding
Figure 5.46. CONTROL Group
BANK dialogue box. Refer to Figure 5.47.
GROUP > or
