Page 2 CPN700i/CPN1010i Multimedia Chart Plotters Owner's Manual CPN700i and CPN1010i Multimedia Chart Plotters Page 3...
Page 3 · The CPN Series Chart Plotter contains dangerous high-voltage circuits which only experienced technicians can handle. · STANDARD HORIZON will not be liable for errors contained herein, or for incidental or consequential damages in connection with the performance or use of this material.
Page 4: Table Of Contents
Selecting Coordinate System ..............34 Loran TD ....................34 Changing the Display Color ............... 34 Selecting Language ................... 35 Chart Control Icon ..................36 2.1.4 SETTINGS IN GENERAL SETUP MENU ..........37 CPN700i and CPN1010i Multimedia Chart Plotters Page 5...
Page 5 2.1.5 QUICK ACCESS TO ALARMS, TRACK AND AIS SETTINGS ....39 Alarms ...................... 39 Track ...................... 39 ...................... 39 CARTOGRAPHY OVERVIEW ................40 2.2.1 BUILT-IN CHARTS - For North America Users Only ........ 40 Updating Built-In Charts ................40 C-MAP 4D ....................42 C-MAP 4D: MAX Content ................
Page 6 2.13.3 CHART PAGE .................... 85 Single ...................... 86 Dual ...................... 86 Data Window Selections ................87 Customizing Data Windows ............... 87 Collapsing Data Windows ................89 Additional Functions on Chart Page: Information on Objects ....90 CPN700i and CPN1010i Multimedia Chart Plotters Page 7...
Page 7 Display Mode ..................... 90 Marine Settings ..................91 Depth Settings ................... 92 Chart Settings .................... 92 Underwater Objects Settings ..............94 2.13.4 NAVIGATION PAGES ................94 Highway Page .................... 94 Chart/Highway Page .................. 95 Compass Page ..................95 GPS Status Page ..................96 GPS Setup Menu ..................
Page 8: Page
MEDIA PLAYER CONTROLS ................144 DISPLAYING PDF FILES ..................146 SAVING FILES ON A USB THUMB DRIVE ............147 6 - INSTALLATION ....................148 MOUNTING THE CPN SERIES CHART PLOTTER ........... 148 CPN700i and CPN1010i Multimedia Chart Plotters Page 9...
Page 9 CARTRIDGES (used by Standard Horizon Technicians) ....... 172 Internal Data Base Test ................172 SD CARD Test ..................172 9.1.4 SERIAL PORTS (used by Standard Horizon Technicians) ....172 Change Parameters ................. 172 Input Data Display ................... 172 Loop-Back Test ..................172 10 - SYSTEM UPDATE ....................
Page 10: Introduction
INTRODUCTION Congratulations on your purchase of the STANDARD HORIZON CPN Series Chart Plotter. Whether this is your first STANDARD HORIZON product or not, we are committed to ensuring your enjoyment and satisfaction with this unit. Our Technical support personnel stand behind every product we sell. Post-Sales Support can be obtained from your local dealer or distributor.
Page 11: Packing List
Accessories and replacements parts may be ordered in North America by contacting STANDARD HORIZON’s Parts department at 714-827-7600 Extn. 6800 or by email at marineparts@yaesu.com. UK customers may contact STANDARD HORIZON at 01962 866667 or by email to service@yaesu.co.uk.
Page 12: Optional Accessories
In addition when a word(s) is bold and underlined it is referring to a menu selection on the display. The screen images on this Owner’s Manual refer to the CPN700i Series Chart Plotter unless specified. CPN700i and CPN1010i Multimedia Chart Plotters...
Page 13: General Operation
1 - GENERAL OPERATION 1.1 POWER UP SEQUENCE 1. Press the PWR key until the display shows the Splash Screen page (see A). 2. The Startup Screen page will be displayed in approximately 30-45 seconds (see B). This page allows selection of the Chart Plotter, Media Player (video, audio and images), ®...
Page 14: Brightness Control
GOTO popup window and allows selection of Go To Cursor, Saved Mark or Route CLEAR key cancels current operation ROUTE key creates Waypoints to make a Route when on the Chart page CPN700i and CPN1010i Multimedia Chart Plotters Page 15...
Page 15: Touchscreen
User Points and update software from an optional SD CARD. 1.2.1 TOUCHSCREEN The CPN700i and CPN1010i use a touchscreen display. Many functions are controlled by touching the display or using the dedicated keys, ShuttlePoint or rotary knobs.
Page 16: Touchscreen Disabling (Chart Plotter Mode Only)
· : (R ) key is touched with a finger. When a key is touched and ACKGROUND released its related function is started. CPN700i and CPN1010i Multimedia Chart Plotters Page 17...
Page 17: Touchscreen Keyboard
· : (G ) the function assigned to this key is not available at the ACKGROUND moment. Touchscreen Keyboard A keyboard is used to enter/edit text of User Points or to type a URL when using the Internet Browser. The keyboard is also used for Internet Browser, Media Player and Connection Manager.
Page 18: Warning Window
The Warning window will be shown to alert you of critical situations. For example: Tap on to close the Warning window. Information Window Above you can see an example of an Information window that shows the CPN Series Chart CPN700i and CPN1010i Multimedia Chart Plotters Page 19...
Page 19: Selecting An Item
1.3.1 KEYS The CPN700i and CPN1010i in addition to being able to control functions with the touch display, also have dedicated keys and knobs provided for your convenience. You will notice when a key is pressed a single beep will be produced which means the key press is valid.
Page 20 · Pressing and holding the key allows for quick zoom. · The key enables the rotary knob for zooming. Rotate the knob clockwise to Zoom In and counterclockwise to Zoom Out. CPN700i and CPN1010i Multimedia Chart Plotters Page 21...
Page 21 For North America users only. The CPN Series Chart Plotters contain Built-In Charts for Alaska, Hawaii and Great Lakes, Canada, Bahamas, Caribbean, Cuba, Mexico, Puerto Rico, and Central America. For more detail, a C-MAP 4D SD CARD must be purchased and installed. Rotary knob ·...
Page 22: Playing Music In Background (Chart Plotter Mode Only)
The cursor is moved over the top of an item (Mark, Waypoint, Route, chart object ...) Only if the Auto Info option is enabled, see Par. 2.1.4 “Settings in General Setup Menu”. CPN700i and CPN1010i Multimedia Chart Plotters Page 23...
Page 23: Closing Soft Keys
· Chart page Touch and hold the Page Change tab (refer to the image below) to show Soft Keys to access other pages. · Other pages (Tide, Highway, Compass, GPS and Fish Finder pages) Tap anywhere on the page to show the Soft Keys: Closing Soft Keys The Soft Keys are closed in the following ways while in Chart Plotter Mode: ·...
Page 24: Chart Plotter
30 seconds. 4. The Splash Screen page (see A) is shown again before the Warning page appears (see C). Move the ShuttlePoint knob down or touch underneath the scroll bar to read the CPN700i and CPN1010i Multimedia Chart Plotters Page 25...
Page 25: Switching Between Modes
Warning page. Tap on to accept the terms. Other Warning pages might appear, tap to confirm. For North America users only: If Built-In Charts are out of date other Warning pages are displayed. 5. When a CPN Series Chart Plotter is first turned on it will take some time for the GPS to acquire a fix of your position.
Page 26: Switching Between 2D And 3D Modes
4. When 3D has been selected (see C), press the key to exit from menu. The screen shows the Chart page in 3D (see D). Using the 1. The Chart page in 2D mode is shown (see A). CPN700i and CPN1010i Multimedia Chart Plotters Page 27...
Page 27: Menu System
Press the key: the following menu appears (see B). 2. To select the 3D mode tap on a desired 3D icon, 3D Vector, 3D Satellite, 3D Raster. 3. As soon as the desired 3D icon has been tapped (see C), the screen shows the selected Chart page in 3D (see D).
Page 28: Initial Setup
5. Tap on Low, Medium or High to set the desired speed. 6. Press the key repeatedly until the menu disappears. 7. Move the cursor on the Chart page and see if the speed is to your liking. CPN700i and CPN1010i Multimedia Chart Plotters Page 29...
Page 29: Changing The Ship Icon
Changing the Ship Icon The Ship Icon may be changed to one of the following icons for Sail or Power: This setting also controls what type of a ship bow is displayed on the Highway page. The default setting is Power boat. To select the Ship Icon you want follow the procedure: 1.
Page 30 · Single tap: changes to the next page. In the example below a single tap on the Page Change tab changes to the Compass page. CPN700i and CPN1010i Multimedia Chart Plotters Page 31...
Page 31: Assigning Page Soft Keys
· Long press: displays the page Soft Keys. To change the page, tap on the desired Soft Key, refer to the image below: tap on the Soft Key to change to the Compass page. The pages defined on the Soft Keys are used to define the page change cycle. Assigning Page Soft Keys The default pages are: The page Soft Keys can be individually customized from the default pages:...
Page 32 8. Tap on to exit the menu and show the last selected page. By setting the time in the steps above, the time shown on the Tide page is automatically set up. CPN700i and CPN1010i Multimedia Chart Plotters Page 33...
Page 33: Selecting Coordinate System
Selecting Coordinate System GPS Coordinates may be changed to show Latitude/Longitude (default ddd.mm.mmm), Loran TDs or UTM. To change the Coordinate System, follow the procedure below: 1. Press the key, tap on Setup Menu. 2. Tap on ADVANCED. The Advanced Setup menu appears. 3.
Page 34: Selecting Language
(such as place’s names and buoy’s names and so on). To select the language you want: CPN700i and CPN1010i Multimedia Chart Plotters Page 35...
Page 35: Chart Control Icon
1. Press the key, tap on Setup Menu. 2. Tap on GENERAL. The General Setup menu appears. 3. Move the ShuttlePoint knob down or turn the rotary knob or touch underneath the scroll bar until LANGUAGE is selected. 4. Tap on LANGUAGE. Another popup window will be shown with the available languages.
Page 36: Settings In General Setup Menu
Depth: selections are ft (feet), ftm (fathoms) and m (meters). The default setting is ft. Altitude: selections are ft (feet) and m (meters).The default setting is ft. Temperature: selections are °F (Fahrenheit) and °C (Celsius).The default setting is °F. CPN700i and CPN1010i Multimedia Chart Plotters Page 37...
Page 37 Air Pressure: selections are bar and hPa. The default setting is hPa. Oil/Boost Pressure: selections are bar, psi and kPa. The default setting is kPa. Fuel: selections are l, UK gal and US gal. The default setting is US gal. Display Color : Changes the background colors to enhance the visibility of the screen depending on the surrounding light conditions.
Page 38: Quick Access To Alarms, Track And Ais Settings
: Defines the TCPA limit. The values allowed are from 1 to 30 Min.The default setting is 10 min. For more information on these settings, please refer to the following paragraphs: for Track Par. 2.10 “Tracks”; for alarms Par. 2.13.10 “Alarms”; for AIS Par. 2.15 “AIS”. CPN700i and CPN1010i Multimedia Chart Plotters Page 39...
Page 39: Cartography Overview
2.2 CARTOGRAPHY OVERVIEW BUILT-IN CHARTS - For North America Users Only 2.2.1 The CPN Series Chart Plotters have Built-In Charts for coastal navigation with the following characteristics (refer to the following image for coverage area of Built-In Charts). · Coverage: USA including Alaska, Hawaii and Great Lakes, Canada, Bahamas, Caribbean, Cuba, Mexico, Puerto Rico, and Central America.
Page 40 (or tap on to abort). 6. The installation process begins. Pay attention: do not turn the CPN Series Chart Plotter Off during installation. The installation status appears in the two progress bars on the CPN700i and CPN1010i Multimedia Chart Plotters Page 41...
Page 41: C-Map 4D
bottom of the package update window (see C): 7. At the end of the installation process, the Startup Screen page is shown. 8. To complete the Built-In Charts update procedure, press the PWR key to turn the CPN Series Chart Plotter Off and remove the Chart Update Card from the slot. 9.
Page 42: Cpn700I And Cpn1010I Multimedia Chart Plotters Page
Waypoints of the shortest Route; highlights potential hazards and displays varying levels of alerts for each segment of the Route, allows you to manually adjust the Route. CPN700i and CPN1010i Multimedia Chart Plotters Page 43...
Page 43: C-Map 4D: Value Added Data
C-MAP 4D: Value Added Data New additional data or service to standard cartography available (High Resolution Bathy- metry, etc). You can enable or disable the display of the category as a whole or of each individual. · High Resolution Bathy Charts & Spot Soundings: data base with high resolution bathy information for an extraordinary view of the seabed depth.
Page 44: Using Find Services
This feature is used to locate nearest Port Services to the position of your vessel. The following table shows a list of some of the available Port Services and icons shown on the Chart page: CPN700i and CPN1010i Multimedia Chart Plotters Page 45...
Page 45: Port
1. Press the key, tap on Chart. 2. Tap on FIND. The Find Services & More menu appears. 3. Tap on PORT SERVICES. A popup window will be shown with a list of different Port Services (see A). 4. Move the ShuttlePoint knob or touch the screen to highlight the desired type of service and tap on .
Page 46: Tide Stations
Soft Key (see C). 3. Tap on the desired Tide Station in the menu (see D). 4. Tap on to show the new Tide information or tap on to exit the menu. CPN700i and CPN1010i Multimedia Chart Plotters Page 47...
Page 47: Wrecks
2.4.4 WRECKS This feature is used to locate the 20 nearest Wrecks to the position of your vessel. A Wreck is represented with an icon on the chart, see the following table: 1. Press the key, tap on Chart. 2. Tap on FIND. The Find Services & More menu appears. 3.
Page 48: Lakes Information
When the cursor is placed over this icon (and the Auto Info option is allowed) the Quick Info window appears: the icons of the available services are shown (see B). CPN700i and CPN1010i Multimedia Chart Plotters Page 49...
Page 49: Lakes By Name
To see the "Fishing" object tap on the Soft Key (see C). Tap on the Soft Key to obtain the Full Info on Lakes: all available information about the cartographic point under the cursor will be shown (see D). 2.4.8 LAKES BY NAME This feature is used to locate nearest Lakes By Name to the position of your vessel.
Page 50: Points Of Interest
Latitude and Longitude. Once the Coordinates are entered tap on the keyboard disappears. The screen shows the desired location on the Chart page. 4. Press the key twice to revert to your vessel’s position. CPN700i and CPN1010i Multimedia Chart Plotters Page 51...
Page 51: Information
2.4.12 INFORMATION This feature allows you to obtain information on any position on the Chart page. 1. Press the key, tap on Chart. 2. Tap on FIND. The Find Services & More menu appears. 3. Turn the rotary knob to select INFORMATION. 4.
Page 52: Display Mode
4. When the item you want has been selected, tap on to exit from menu. Overlay This function allows to overlay Vector (default) (see A), Satellite image (see B), Raster Charts (see C) or Chart Shading (see D) for background charts. CPN700i and CPN1010i Multimedia Chart Plotters Page 53...
Page 53: Overlay Mode
To activate this function follow the procedure: 1. Press the key, tap on Setup Menu. 2. Tap on DISPLAY. The Chart Display menu appears. 3. Tap on OVERLAY. 4. The menu shows Satellite, Raster Charts, Chart Shading or Vector. Tap on the item you want.
Page 54: General Chart Display Functions
Standard (see A), Medium (see B) and Large (see C) size. To activate this function follow the procedure: 1. Press the key, tap on Setup Menu. 2. Tap on DISPLAY. The Chart Display menu appears. CPN700i and CPN1010i Multimedia Chart Plotters Page 55...
Page 55: Safety Status Bar (Dsi - Data Safety Indicator)
3. Tap on PLACE NAMES SIZE. 4. The menu shows Standard, Medium or Large. Tap on the item you want. 5. Tap on to exit to the Chart page. Safety Status Bar (DSI - Data Safety Indicator) When the Safety Status Bar is enabled, a status bar with six boxes shows the status of certain functions.
Page 56: Chart Language
English : Always uses English. Local : Uses the local language present on C-MAP B SD CARD. If no local EPPESEN language is available, English is used. 5. Tap on to exit to the Chart page. CPN700i and CPN1010i Multimedia Chart Plotters Page 57...
Page 57: Course Up/North Up
a. When the Chart Language is changed, the following settings are automatically selected: MODE is set to Off and Chart Language is set to your selection. b. If the SD CARD is removed or changed, the Chart Language should be confirmed and changed if necessary.
Page 58: Course Time Line
Chart page (if Bottom selected). It applies only to Home Mode. To activate this function follow the procedure: 1. Press the key, tap on Setup Menu. 2. Tap on DISPLAY. The Chart Display menu appears. CPN700i and CPN1010i Multimedia Chart Plotters Page 59...
Page 59: Pictures & Diagrams
3. Turn the rotary knob to select SHIP ICON POSITION. 4. Tapping on SHIP ICON POSITION selects between Center and Bottom. 5. When the item you want has been selected, tap on to exit to the Chart page. 2.5.3 PICTURES & DIAGRAMS Using optional C-MAP data SD CARDs allows you to show pictures or diagrams EPPESEN...
Page 60: Creating Marks
After entering in all the Marks it is a good practice to backup the points to a SD CARD. 2.6.2 EDITING A MARK OR WAYPOINT 1. Tap on the Mark or Waypoint you want to edit. CPN700i and CPN1010i Multimedia Chart Plotters Page 61...
Page 61: Deleting A Mark Or Waypoint
2. Tapping on the Soft Key shows the Mark Edit popup window. 3. The Mark Icon appears selected, tap on it. The Mark Icons popup window appears. 4. Tap on the desired Mark Icon to select it. The Mark Icons window disappears. 5.
Page 62: Marks/Waypoints (User Points) List
Receive points from an external device (PC) that is capable of sending NMEA-0183 WPL sentence. An information window appears after receiving completed. Tap on to confirm. The SEND and RECEIVE functions are usually used by navigation programs running on a PC. CPN700i and CPN1010i Multimedia Chart Plotters Page 63...
Page 63: Creating/Modifying A Mark In User Points List
2.6.6 CREATING/MODIFYING A MARK IN USER POINTS LIST This function is very useful if you have a list of Marks that you want to enter into the CPN Series Chart Plotter. 1. Press the key, tap on User Points. 2. Tap on MARKS. The Marks/Waypoints List page will be shown. 3.
Page 64: Routes
You will notice another Waypoint is shown under the cursor and a line joins the starting Waypoint to the second Waypoint. 5. Repeat steps 3 and 4 until all Waypoints are entered into the Route. CPN700i and CPN1010i Multimedia Chart Plotters Page 65...
Page 65: Changing The Name Of A Route
At this point the Route is saved as ROUTE01. If you would like to save the Route under a specific name follow the next steps. 2.7.2 CHANGING THE NAME OF A ROUTE 1. To name the Route move the ShuttlePoint knob or touch the screen on the Route (on a Waypoint or on a leg).
Page 66: Creating A Route Using Marks On The Chart Page
ShuttlePoint knob (if enabled) (see C). When in 3D mode, the 2D mode is automatically triggered. When a Waypoint is placed, the CPN Series Chart Plotter remains in 2D mode. CPN700i and CPN1010i Multimedia Chart Plotters Page 67...
Page 67: Deleting A Route
2.7.7 DELETING A ROUTE To delete a Route follow the procedure below: 1. Press the key, tap on User Points. 2. Tap on ROUTE. 3. Tap on DELETE. You can touch the Route and then press the Soft Key instead of step 1, 2 an 3. 4.
Page 68 (like DSC, MOB, Mark). In the case of checking a single point towards which the navigation is started, the leg for which the Route Check is executed is defined by the current position (the leg’s starting point) and the destination point (the leg’s ending point). CPN700i and CPN1010i Multimedia Chart Plotters Page 69...
Page 69: Easy Routing (Er)
2.7.10 EASY ROUTING (ER) C-MAP AVAILABLE WITH OPTIONAL EPPESEN ARTOGRAPHY ONLY Easy Routing calculates the shortest safe Route between two chosen points. Please note that the calculation of complex Routes can be time consuming. With Easy Routing given a Start Point and End Point the CPN Series Chart Plotter will automatically propose the shortest safe Route connecting the two points.
Page 70 ShuttlePoint knob or tap on the display to select the starting point, (see C) and then tap on the Soft Key, to define the Start point. A new window appears (see D). CPN700i and CPN1010i Multimedia Chart Plotters Page 71...
Page 71: Warning Messages
7. Tap on CURSOR. The Start point is set on the cursor position (see E). 8. Then move the ShuttlePoint knob or tap on the display to select the destination point and then tap on the Soft Key, to define the End point. A new window appears.
Page 72: Easy Routing Touchscreen Commands
2. Press the key and a GOTO popup window will be shown (see A). If an Easy Routing Route exists it will also be listed in the GOTO popup window (ER item). CPN700i and CPN1010i Multimedia Chart Plotters Page 73...
Page 73: Goto A Route
3. Tap on CURSOR. 4. The CPN Series Chart Plotter now navigates from your current position to the location selected at step 1. A bearing line between the vessels location and the destination point is shown. A popup window shows the Distance (DST) and Bearing (BRG) from the vessel’s location to the destination point (see B and C).
Page 74: Using The Shuttlepoint Knob
MOB function has been activated, tap on 2. Press the key. You will notice a MOB Mark on the Chart page and all navigation is referring back to this point (see A). CPN700i and CPN1010i Multimedia Chart Plotters Page 75...
Page 75: Deleting A Mob Point
3. To stop navigation to the MOB point, press the key: the Soft Keys are displayed (see B), tap on 2.9.2 DELETING A MOB POINT 1. After stopping navigation to the MOB point, tap on the MOB icon. The Soft Keys appear (see A).
Page 76: Saving And Starting A New Track
4. Enter the next Track number using the touchscreen keyboard. Tap on to select the new Track. 5. Tap on TRACKING to start laying down Track Points. 6. Tap on to exit the menu to the Chart page. CPN700i and CPN1010i Multimedia Chart Plotters Page 77...
Page 77: Deleting A Track
2.10.2 DELETING A TRACK 1. Press the key, tap on User Points. 2. Tap on TRACK. 3. Tap on ACTIVE TRACK. 4. Enter the Track number using the touchscreen keyboard. Tap on 4. Tap on DELETE. 5. A Warning window will be shown to confirm if you want to reset the Track. Tap on The Track is now deleted.
Page 78: Resetting The Trip Log
Warning window is shown and an audible alarm sounds (only if the Audible Alarm option is set On, see Par. 2.13.10 “Alarms”): tap on to close the Warning window. The counter value is reset to the previously set starting value. CPN700i and CPN1010i Multimedia Chart Plotters Page 79...
Page 79: Setting The Count Down Timer
Setting the Count Down Timer When Count Down Timer is shown in one of the data windows, you can set the required starting value, and/or start/stop the timer, following the procedure below. 1. Press and hold the key until a field is highlighted (it will be shown in a yellow frame). 2.
Page 80: Handling The Trip Timer
Tap on STOP to stop counting down, the current counter value is remembered. The data customization box will be closed. The max TRT value is 999:00:00. When the Trip Timer reaches 999 hours, it will keep counting but will display in the databox “>999”. CPN700i and CPN1010i Multimedia Chart Plotters Page 81...
Page 81: User Sd Card
User Points when the RAM has to be cleared to resolve an issue or load new Software, or if you would like to transfer Waypoint, Track and Route information from one STANDARD HORIZON CPN Series Chart Plotter to another. To select the User SD CARD menu follow the procedure: 1.
Page 82: Transferring Files To A User Sd Card
4. Select the saved file from the User SD CARD list by tapping on it. 5. Tap on the Soft Key. The Warning window appears to confirm you want to delete the file. 6. Tap on to confirm. CPN700i and CPN1010i Multimedia Chart Plotters Page 83...
Page 83: Refreshing A User Sd Card
2.12.5 REFRESHING A USER SD CARD If you opened the User SD CARD page, you may want to change the User SD CARD inserted in the slot with a new one. If a cartographic SD CARD is inserted into the slot, do not follow the procedure below. Please refer to Par. 2.3 “Removing the SD CARD”).
Page 84: Selecting A Page Or Menu
The Chart page is the main page of the CPN Series Chart Plotter. From this page you can zoom in/out, pan around the chart, show information about cartographic objects, see the exact vessel position with the COG and SOG, place points, GOTO a destination point, show CPN700i and CPN1010i Multimedia Chart Plotters Page 85...
Page 85: Single
Track history etc. 1. Press the key, tap on Chart. In the bottom of the page the available icons appear: SINGLE opens the Chart page, DUAL opens the Dual Chart page, & HIGHWAY opens the Chart/Highway page, FIND opens the Find Services & More menu and C-WEATHER opens the C-Weather page.
Page 86: Data Window Selections
Course Over Ground · HDG Heading from Electronic Compass · ALT Altitude · HDOP Horizontal Dilution of Precision · VDOP Vertical Dilution of Precision · DATE Current Date · TIME Current Time CPN700i and CPN1010i Multimedia Chart Plotters Page 87...
Page 87 NAVIGATION selections · DST Distance to navigated point · BRG Bearing to navigated point · XTE Cross Track Error · TTG Time To Go · CDT Count Down Timer · STR Steering Angle · TLOG Trip Log · TRT Trip Timer ·...
Page 88: Collapsing Data Windows
· If the Data Window is collapsed, touching the icon expands the Data Window back to 1 line large / 1 line small / 2 lines small or touching the icon expands the General. CPN700i and CPN1010i Multimedia Chart Plotters Page 89...
Page 89: Additional Functions On Chart Page: Information On Objects
Additional Functions on Chart Page: Information on Objects When on the Chart page you will notice icons of Buoys, Towers, Lights, Wrecks, Tide Stations, Port Icons, and so on. If the cursor is moved over the top of these icons a popup window will be shown containing information about the icon (this is possible only if the Auto Info function is enabled).
Page 90: Marine Settings
GPS or the CPN Series Chart Plotter is not in Simulation Mode, the icon on the chart is generic one. The color of the arrow denotes the strength of the current as follows: CPN700i and CPN1010i Multimedia Chart Plotters Page 91...
Page 91: Depth Settings
When the CPN Series Chart Plotter receives a valid position fix, the Tide icons are shown on the charts on the basis of the current date and time: the screen displays and changes arrows as date/time changes. Seabed Type : Turns the Seabed Type On or Off. Ports &...
Page 92 The Safety Status Bar DSI (Data Safety Indicator) window, if present, will show “NO CHART”, when the CPN Series Chart Plotter is zoomed into a chart level which does not contain cartographic data. CPN700i and CPN1010i Multimedia Chart Plotters Page 93...
Page 93: Underwater Objects Settings
Underwater Objects Settings The following selections are used to control which Underwater Objects are shown on the Chart page. Underwater Object Limit : Selects the max depth value to display Underwater Objects. If value is set to 0ft, the Underwater Objects are not shown on the chart display.
Page 94: Chart/Highway Page
2. Tap on COMPASS. The Compass page appears. Data Boxes on the Compass page can be customized, except for Latitude, Longitude, GPS Status, COG and BRG. Tapping anywhere on the screen brings up the Soft Key. CPN700i and CPN1010i Multimedia Chart Plotters Page 95...
Page 95: Gps Status Page
GPS Status Page This page is used as a reference to see how well the GPS is receiving satellites. 1. Press the key, tap on Navigation. 2. Tap on GPS. The GPS Status page appears. Data Boxes can be customized, except for Latitude, Longitude and GPS Status.
Page 96: Nmea
Soft Keys to appear, and then tap on the desired Soft Key to select the NMEA Digital page you want. For example tap on the Soft Key to open NMEA Digital page with 6 boxes. See the following picture. CPN700i and CPN1010i Multimedia Chart Plotters Page 97...
Page 97: Customizing Data Boxes In The Nmea Digital Page
The 3 BOXES configuration is useful when navigating to a destination and trying to keep the Course Over Ground (COG) and Bearing (BRG) figures the same. Customizing Data Boxes in the NMEA Digital Page To customize a data box please follow the procedure below: 1.
Page 98: Analog Page
NMEA. 2. Tap on MONITOR. The display should look similar to the following picture (see A). The currently selected source of data is shown in the bottom right corner of the page. CPN700i and CPN1010i Multimedia Chart Plotters Page 99...
Page 99: Fish Finder (Optional Ff525 Required)
3. To view data from another port or device, tap anywhere on the page for the Soft Keys to appear (see B). 4. Tap on the Soft Key. A window with available options will appear. 5. Tap on the desired port or device in the list. 6.
Page 100: Vhf Digital Selective Calling
1. A vessel that has transmitted a DSC Distress Call 2. A vessel that has transmitted a DSC Position Send Call 3. The position of a vessel that transmitted a DSC Position Request Call CPN700i and CPN1010i Multimedia Chart Plotters Page 101...
Page 101: Nmea-0183/Nmea-2000 Interfacing
NMEA-0183/NMEA-2000 Interfacing To take advantage of these functions the CPN Series Chart Plotter must be interfaced (wired) to a STANDARD HORIZON or compatible DSC VHF. Refer to Chapter 7 “Connections” for connection example. DSC data can be received both from NMEA-0183 and NMEA-2000 relevant instruments, without any priority.
Page 102: Dsc Directory
CPN Series Chart Plotter will stop streaming its screen image to the mobile device. The P2N Link function will be resumed when the Video Input function is quitted. CPN700i and CPN1010i Multimedia Chart Plotters Page 103...
Page 103: Video Input Menu
1. Press the key, tap on Page Icon Video Input. 2. Select the video image type: for CPN700i tap on VIEW1 or PIP1, for CPN1010i tap on VIEW1, VIEW2, PIP1 or PIP2 as you want. After the video image type has been selected, the CPN Series Chart Plotter will show a Warning message with the instructions to adjust the image from the Video Input: tap on to close the Warning window and activate the video in.
Page 104: Alarms
Alarm will be shown). The CPN Series Chart Plotter shows an icon on the charts that identifies when a Grounding Alarm is detected. CPN700i and CPN1010i Multimedia Chart Plotters Page 105...
Page 105: Engine Alarm Report
Engine Alarm Report This menu is used to display the Engine Alarm Report on ENGINE-0 , ENGINE-1 ENGINE-2 . These alarms cannot be disabled or enabled by a user; they appear when a NMEA-2000 sentence with warning information is received (of course these alarms work only when engines are connected to NMEA-2000 bus).
Page 106: System Alarm Report
Lat/Lon coordinates. To use the TD Coordinate System the user must set up the Chain and Pair information of the TDs. If you do not know this information, refer to paper charts that show the Chain and Pair information. See the following table: CPN700i and CPN1010i Multimedia Chart Plotters Page 107...
Page 107: Compass (Cog) Setup
Chain : Selects the Chain. Pair : Selects the Pair. ASF1/2 : Additional Secondary phase Factor Correction to TD1/2 values which can be inserted by the user to take into account the additional signal propagation delay over a mixed land/seawater path compared to an all- seawater path.
Page 108: Engines Name Selection
Engine. Insert the desired name (6 characters long); when finished tap on , the keyboard disappears. 2.14.5 INPUT/OUTPUT (NMEA-0183) CONNECTIONS Refer to Chapter 7 “Connections” for wire description and connection examples. CPN700i and CPN1010i Multimedia Chart Plotters Page 109...
Page 109: Input/Output
Input/Output The CPN Series Chart Plotter has 3 NMEA-0183 inputs and 4 NMEA-0183 outputs. These Ports may be set up to receive and output the following: · NMEA-0183 - NMEA-0183 devices set to 4800 Baud (default setting) · GPS Auto - External GPS devices of unknown or different than 4800 Baud. The system will automatically detect connected GPS’s Baud Rate and will allow correct communication with this device.
Page 110: Navigating A Route In Simulation Mode
Position Request icon and show the Position Request popup window 2.14.8 ABOUT PAGE The About page contains software, chart and optional devices information. To select the CPN700i and CPN1010i Multimedia Chart Plotters Page 111...
Page 111: Dam Report Page
About page follow the procedure below: 1. Press the key, tap on Setup Menu. 2. Tap on the right bottom arrow to scroll the Desktop Icons to display ABOUT and tap on it. The About page appears on the screen (see A). 3.
Page 112: Ais
· Receive details from other vessels or navigation aids within VHF range. CPN Series Chart Plotters are able to display AIS Targets (for collision avoidance) on the Chart page and AIS List pages when connected to an AIS Receiver (GX2100 or GX2150 CPN700i and CPN1010i Multimedia Chart Plotters Page 113...
Page 113: System Definitions
STANDARD HORIZON VHF/AIS transceiver) or transponders which output NMEA-0183 VDM sentence at 38400/4800 baud, or output NMEA-2000 . The CPN Series Chart Plotters are able to show Targets from both Class A (commercial) and Class B Targets. AIS data can be received both from NMEA-0183 and NMEA-2000 relevant instruments, without any priority.
Page 114: Ais Setup Menu
The selected AIS Target icon is surrounded by a square frame when user places the cursor over the icon. 2.15.4 AIS TARGET COLORS The received AIS Targets are shown in color. The color depicts the type of AIS ship shown on the Chart page. Refer to following table. CPN700i and CPN1010i Multimedia Chart Plotters Page 115...
Page 115: Ais-Sart
2.15.5 AIS-SART AIS-SART, AIS-MOB and AIS-EPIRB signals are all emergency signals sent out by different types of survivor locating devices. When an AIS-SART, AIS-MOB or AIS-EPIRB signal is received, the CPN Series Chart Plotter displays and sounds a dedicated alarm. It also displays such objects on the Chart page like any other AIS objects but with dedicated icons, depending on the current status of the emergency signal (see the following table).
Page 116: C-Map Weather Forecasts Service
· Wave Height and Wave Direction · Air Temperature · Level of Humidity · Visibility in miles and weather type The units of measure are set by the user, see Par. 2.1.4 “Settings in General Setup Menu”. CPN700i and CPN1010i Multimedia Chart Plotters Page 117...
Page 117: C-Map Weather Page
2.16.1 C-MAP WEATHER PAGE To select the C-Weather page: 1. Press the key, tap on Chart. 2. Tap on C-WEATHER. The C-MAP Weather page appears: Downloaded data is shown directly on the chart and detailed information about each data is displayed in a dedicated window. C-Weather page can be exited like any other page by: going to the Main Menu and choosing a different page;...
Page 118: Download From Sd Card
By default the C-Weather Forecast is displayed over 2D Vector chart, but you can change this mode (see Par. 2.5.1 “4D Functions”). CPN700i and CPN1010i Multimedia Chart Plotters Page 119...
Page 119: P2N Link
The following functions are available: · Panning: default usage of the cursor key is the normal panning function. · Zoom in/out: zoom in/out functions are allowed as usual by using Zooming and panning are allowed and accessible as like on any other Chart page. In fact C-Weather page behaves like any other Chart page, but quick info on cartographic object and User Points does not work.
Page 120: P2N Link Activation On Cpn Series Chart Plotter
P2N Link can be established by connecting via one of the following connections: ® ® Wi-Fi Hotspot, CPN Wi-Fi network or the Ethernet router (see B1, B2, B3 for connection window examples) CPN700i and CPN1010i Multimedia Chart Plotters Page 121...
Page 121: P2N Link Deactivation
4. Choose the available connection type and tap on to activate the connection and P2N Link function (tap on to close the window without taking any action). 5. Once the connection is set and the P2N Link function is activated, the following windows will be displayed (see C1 and C2).
Page 122 6. Once a connection is estabilished (see connection status), tap on (see D). 7. If the connection is properly established, the screen image of the selected CPN Series Chart Plotter will be shown on the iOS device (see E). CPN700i and CPN1010i Multimedia Chart Plotters Page 123...
Page 123: P2N Link Deactivation On Mobile Device
Tap on to see the same image dimension as on the CPN Series Chart Plotter screen, or tap on to enlarge the image to fit to iOS device screen. The quality of the image might be affected by the quality of the connection. When the signal level is poor, the image might be scattered, some frames might be lost and in the worst cases the image might turn green.
Page 124: Connection Manager
Startup Screen page. 3. When the Startup Screen page is shown, tap on the Connect Icon (see A). From the Startup Screen Page 1. Turn on the CPN Series Chart Plotter. CPN700i and CPN1010i Multimedia Chart Plotters Page 125...
Page 125: Wi-Fi® Connection
2. When the Startup Screen page is shown, tap on the Connect Icon (see A). The first time the Connection Manager is opened, the following window is displayed: Please restart your CPN Series Chart Plotter unit after using the Connection Manager for the first time.
Page 126: How To Connect To Wi-Fi® Hotspot
Hotspot by using the Authentication Information (password) stored. 5. If the CPN Series Chart Plotter was not connected to the Hotspot before, and the Hotspot requires a Network (Password) Key, the configuration page will be displayed. CPN700i and CPN1010i Multimedia Chart Plotters Page 127...
Page 127: Cpn Wi-Fi Network
At the start up the Connection Manager automatically tries to connect to the latest used Hotspot. If the latest selected Hotspot is no longer available or if it has a weak signal, the Connection Manager creates CPN Wi-Fi ® Ad-hoc network (for more details please refer to Par. 3.3.3). The Connection Manager will show the parameters of the selected Hotspot.
Page 128: Networking Connection: C-Map 4D Charts, Nmea & Fish Finder Data Sharing
Refer to the following images to identify the Ethernet port on your CPN Series Chart Plotter. 2. Press and hold the PWR key to turn on both Chart Plotters. Please see also the Par. 7.1.9 “Second CPN to share C-MAP 4D Charts, NMEA & FF data”. CPN700i and CPN1010i Multimedia Chart Plotters Page 129...
Page 129: Chart Plotter 1 Setup (With C-Map 4D Card Inserted)
Chart Plotter 1 Setup (with C-MAP 4D CARD inserted) 1. When the Startup Screen page is shown, tap on the Connect Icon (see A). 2. The next display shown is the Connection Manager (see B), tap on the Services tab. 3.
Page 130: Chart Plotter 2 Setup (No Chart Inserted)
3. Check that Vector Chart Sharing (see H) is disabled (otherwise if both CPN Series Chart Plotters are configured with the Vector Chart Sharing option enabled, vector charts will not be shared): CPN700i and CPN1010i Multimedia Chart Plotters Page 131...
Page 131: Ethernet Configuration
The setting is related to the P2N Link functionality (see Par. 2.17). Please note that if you are using the Vector Chart Sharing option, it would be better to not choose Ethernet in this setting to avoid overloading network. 4. Tap on the Ethernet tab (see I) to configure the network settings: 5.
Page 132: Pairing The Cpn Series Chart Plotters With Bluetooth® Wireless Technology
1. When the Startup Screen page is shown, tap on the Connect Icon (see A). 2. The next display shown is the Connection Manager (see B), tap on the tab called Bluetooth ® CPN700i and CPN1010i Multimedia Chart Plotters Page 133...
Page 133: Pairing Bluetooth® Device
3. The Soft Key displayed at the bottom right corner of the screen (see C) switches the ® Bluetooth wireless device OFF or ON. The Soft Key indicates the status of the ® Bluetooth wireless device after pressing the Soft Key: ®...
Page 134: Unpairing Bluetooth® Device
1. Double tap on your device in the Trusted list to display the menu (see L) and tap on Delete to remove the device. CPN700i and CPN1010i Multimedia Chart Plotters Page 135...
Page 135: Internet Browser
4 - INTERNET BROWSER 4.1 GETTING STARTED The Getting Started section will take you through frequently used operations using the Browser. The Browser is a software application which allows you to navigate the web and display Internet pages. Browser supports the following 16 languages: ·...
Page 136: Browser Overview
If no Wi-Fi® network connection is available the Connection Manager page is automatically opened. When a connection is established and the Connection Manager is closed, the Browser is automatically launched. 4.3 BROWSER OVERVIEW CPN700i and CPN1010i Multimedia Chart Plotters Page 137...
Page 137: Internet Browser Controls
The Browser Home page is displayed when the Browser is launched (see C): when loading is completed the green progress bar disappears and the Stop icon is replaced by the Reload icon (see D). 4.3.1 INTERNET BROWSER CONTROLS Page 138 Owner’s Manual...
Page 138: How To Navigate
It is possible · to open links contained in the page by simply tapping on them. · to scroll the page press a finger on the screen and move the finger in any direction. CPN700i and CPN1010i Multimedia Chart Plotters Page 139...
Page 139: The Favorites Page
4.5 THE FAVORITES PAGE When navigating, you may find a page you wish to recall afterward. The Internet Browser has a list of pre-defined favorite addresses (Bookmarks), but it allows adding and removing pages to and from the favorites list. To add the currently opened page to the favorites list, tap on the Add-Favorite icon When a website is present in the favorites list, the Add-Favorite icon turns to Remove-...
Page 140: Playing Media Contents
The PDF file will be downloaded and displayed (see Par. 5.5 “Displaying PDF files”). PDF files will be displayed in a dedicated application. After closing the application the web page containing the link to the PDF will be displayed again. CPN700i and CPN1010i Multimedia Chart Plotters Page 141...
Page 141: Media Player
5 - MEDIA PLAYER 5.1 GETTING STARTED The Getting Started section will take you through frequently used operations using the Media Player functionality. It is possible to open the Media Player functionality in two modes: · as a standalone application (accessed from Startup Screen) ·...
Page 142: Overview
2. Start the Media Player from the Startup Screen page (see A) or by pressing the Intelligent key on the front of the CPN Series Chart Plotter when in Chart Plotter Mode. CPN700i and CPN1010i Multimedia Chart Plotters Page 143...
Page 143: Media Player Controls
3. Tap on the drop down list to select the media device and display its content (see B): 4. Tap on the folder to be viewed (example Audio), see C: 5. Tap on the multimedia file to play (see D): The selected multimedia file will automatically begin to play.
Page 144 CPN700i and CPN1010i Multimedia Chart Plotters Page 145...
Page 145: Displaying Pdf Files
5.5 DISPLAYING PDF FILES A PDF file is displayed as shown below (see A): Viewing PDF files: · scroll the page up and down: a. Press and hold the finger on the page and then drag it from up to down: page goes up.
Page 146: Saving Files On A Usb Thumb Drive
PDF files stored on the USB Thumb Drive, ready to use (see the Par. 5.3 “Overview”). If you want to save files on SD CARD, a SD CARD Reader is needed. The saving files procedure is the same. CPN700i and CPN1010i Multimedia Chart Plotters Page 147...
Page 147: Installation
6 - INSTALLATION 6.1 MOUNTING THE CPN SERIES CHART PLOTTER The CPN Series Chart Plotters are supplied with a swivel mounting bracket which allows them to be dash mounted. When flush mounting, the optional GPS Antenna may be needed to receive GPS satellite signals. Refer to the images below for bracket installation: When choosing a location to bracket mount a CPN Series Chart Plotter it is advisable to temporarily connect the CPN Series Chart Plotter to power, enter Chart Plotter Mode and check the signal strengths by touching on the Navigation icon, and touching the GPS Status icon.
Page 148: Flush Mounting The Cpn Series Chart Plotter
FLUSH MOUNTING THE CPN SERIES CHART PLOTTER The CPN Series Chart Plotters are supplied with a flush mount cutout template and a flush mount kit. Refer to the images below as a guide to installing. CPN700i and CPN1010i Multimedia Chart Plotters Page 149...
Page 149 Before drilling holes make sure there is enough room to mount the CPN Series Chart Plotter and there are no obstructions. 1. After a location is found, peel the template label from the backing and apply the label to the mounting area. 2.
Page 150: Mounting The Optional External Gps Antenna
4. Insert the cable into the 0.78” (20mm) hole and route to the CPN Series Chart Plotter. 5. Apply a small amount or RTV to the underside of the antenna and place onto mounting surface. Allow time for the antenna to adhere to the mounting surface. CPN700i and CPN1010i Multimedia Chart Plotters Page 151...
Page 151: Connections
7 - CONNECTIONS 7.1 OVERVIEW The CPN Series Chart Plotter has connectors that allow it to be connected to: · Battery Connections · NMEA-0183 Devices (VHFs, AIS Receiver, Digital Instruments and Autopilots) · Optional FF525 BLACK BOX FISH FINDER · Optional Video Camera ·...
Page 152: Battery Connections
4. This cable has many wires, however only the Red and Black wires are used to connect to a switched battery supply. Refer to the following images. For additional connections refer to Par. 7.1.2 “NMEA-0183 Connections”. CPN700i and CPN1010i Multimedia Chart Plotters Page 153...
Page 153: Warning: Product Installation And Operation
Warning: Product Installation and Operation This product must be installed by professional personnel in accordance with the instructions provided. Failure to do so could result in personal injury, damage to your boat and/or poor product performances. Warning: Product Grounding Before powering this product, please make sure it is correctly grounded to your Boat Ground following the installation instructions below.
Page 154 2. Please connect the Red wire of the Power Cable at its termination to the Boat Ground. 3. Please connect the Black wire of the Power Cable at its termination to the Boat Ground. If not available, it could be the engine chassis. CPN700i and CPN1010i Multimedia Chart Plotters Page 155...
Page 155: Nmea-0183 Connections
4. Please connect the Red and Black wires of the Power Cable respectively to the positive and negative poles of the Boat Battery. In the pictures indicates Boat Battery, Boat Ground and Power Cable. 7.1.2 NMEA-0183 CONNECTIONS The CPN Series Chart Plotter is supplied with two accessory cables. These two cables may be connected to PWR/ACC1 or ACC2 connections.
Page 156 CPN700i and CPN1010i Multimedia Chart Plotters Page 157...
Page 157: Pwr/Acc1 Connections
When NMEA-0183 4800 is selected the CPN Series Chart Plotter allows selection of the NMEA-0183 Output sentences. The NMEA-0183 sentences read from external devices are listed in the Par. 8.1 “CPN700i” and Par. 8.2 “CPN1010i”. To enable or disable output sentences follow the procedure below: 1.
Page 158 By default the CPN Series Chart Plotters PWR/ACC1 Port2 connection is set to Fish Finder. When an optional FF525 is connected Port2 Input (Gray) and Output (White) wires are not used for connections to other devices. CPN700i and CPN1010i Multimedia Chart Plotters Page 159...
Page 159 Page 160 Owner’s Manual...
Page 160: Video Input Connections
2 NTSC or PAL Compatible Inputs: NTSC or PAL Video Inputs allow a camera, DVD or VCR to be connected. To connect a video source, use the optional ACVC10 cable (3 pin to RCA phone adapter). CPN700i and CPN1010i Multimedia Chart Plotters Page 161...
Page 161: Pre-Amp Output-External Amplifier/Speaker Connections
Amplifier. To connect an External Amplifier to the Pre-Amp Output an optional ACAC10 Adapter Cable will have to be purchased separately. The following is an example of connections: CPN Pre-Amp Connector Pin Out CPN700i/CPN1010i LINE Output Connector Description Channel right + Channel right - (GND)
Page 162: Optional Usb Thumb Drive
WAAS (Wide Area Augmentation System). The GPS engine, interface electronics and the passive antenna are enclosed inside the waterproof plastic housing. This provides advanced state of the art GPS performance in an easy to use package. CPN700i and CPN1010i Multimedia Chart Plotters Page 163...
Page 163: Optional Ff525 Black Box Fish Finder
7.1.7 OPTIONAL FF525 BLACK BOX FISH FINDER Page 164 Owner’s Manual...
Page 164: Optional External Alarm Connection
Two CPN Series Chart Plotters may be linked together using an optional Ethernet crossover cable to share optional C-MAP 4D cartography, NMEA and Fish Finder data. Refer also to Par. 3.4 “Networking Connection: C-MAP 4D Charts, NMEA & Fish Finder Data Sharing”. CPN700i and CPN1010i Multimedia Chart Plotters Page 165...
Page 165: Nmea-2000 Devices
7.1.10 NMEA-2000 DEVICES The CPN Series Chart Plotters allow connection to a NMEA-2000 network, to connect marine electronic equipment on vessels. The devices connected by NMEA-2000 have the ability to share data with other devices over a single bus. The following is an example of a NMEA-2000 connection: The list of PGNs is shown in the “Specification”...
Page 166: Specifications
Line Out : 4VRMS (max) at 20K 0HM ® Wi-Fi Antenna : external SMA connector ® Wi-Fi Certification : 802.11b/g/n ® Bluetooth : v. 2.1 + EDR. HID (mouse and keyboard) profile only CPN700i and CPN1010i Multimedia Chart Plotters Page 167...
Page 167: Cpn700I Dimensions
8.1.1 CPN700i DIMENSIONS 8.2 CPN1010i Power Supply : 10-35 VDC Power Consumption : 19W max Current Draw: 1.6A@12VDC Display : 10” Wide SVGA Resolution: 1024 x 600 Sunlight viewable Backlight: LED (1000nits) Touchscreen: Capacitive Cartography : C-MAP 4D SD CARD Operating temperature range : 32°F/+131°F (0°C/+55°C)
Page 168: Cpn1010I Dimensions
: 4VRMS (max) at 20K 0HM ® Wi-Fi Antenna : external SMA connector ® Wi-Fi Certification : 802.11b/g/n ® Bluetooth : v. 2.1 + EDR. HID (mouse and keyboard) profile only 8.2.1 CPN1010i DIMENSIONS CPN700i and CPN1010i Multimedia Chart Plotters Page 169...
Page 169: Optional Ff525 Fish Finder
: 5ft at 50kHz, 2.5ft at 200kHz Maximum Depth : 1500ft at 50kHz, 700ft at 200kHz Airmar X-DUCER ID : Must use STANDARD HORIZON transducers part numbers Advanced Digital Signal Processing Speed & Temperature Sensor (if available on transducer) Alarms (Shallow Water, Depth, Fish, Temp)
Page 170: Technical Tests
Test it is needed to hold down any key while the Chart Plotter application is starting: 1. Select the Startup Screen page. 2. Tap on the Plotter Icon , when the STANDARD HORIZON Splash Screen page is shown, press and hold the key until the System Test display is shown, then let go of the key.
Page 171: Backlight
3. If there is not any SD CARD inserted in the slot, the message "not present" is shown. 9.1.4 SERIAL PORTS (USED BY STANDARD HORIZON TECHNICIANS) If you are having problems receiving data from the position-finding instrument, this test should help determine the problem.
Page 172: System Update
SD CARD. This operation might require several minutes (if you want to abort the installation tap on At the end of the checking, the package update window shows the following data (see B). The touchscreen key is now selected (it appears with blue frame). CPN700i and CPN1010i Multimedia Chart Plotters Page 173...
Page 173: System Update Error Messages
7. Tap on to start installation (or tap on to abort). Otherwise move the ShuttlePoint knob to place cursor on (or on to abort) and then press the ShuttlePoint or rotary knob. 8. The installation process begins. Pay attention: do not turn the CPN Series Chart Plotter Off during installation. The installation status appears in the two progress bars on the bottom of the package update window (see C): 9.
Page 174: Error Message 08
Plotter and then follow the procedure: 1. Download the Installation Package and install it on the SD CARD (or contact your dealer to obtain the proper Installation Package). 2. Execute the installation procedure. CPN700i and CPN1010i Multimedia Chart Plotters Page 175...
Page 175: Terms
TERMS ® AES (Advanced Encryption Standard): Wi-Fi authorized strong encryption standard. It uses a Pre-Shared Key (PSK) that is 8 or more characters in length, up to a maximum of 63 characters. AIS (Automatic Identification System): Improves the safety of navigation by assisting in the efficient operation of ship-to-ship location reporting and VTS applications.
Page 176 TRT (Trip Timer): Measures elapsed time between two moments in time (e.g. the beginning and the end of the trip). TWD (True Wind Direction): Shows the True Wind Direction when an external wind instrument with NMEA is connected. CPN700i and CPN1010i Multimedia Chart Plotters Page 177...
Page 177 TWS (True Wind Speed): Shows the True Wind Speed when an external wind instrument with NMEA is connected. TTG (Time To Go): Shows time to go to reach a Destination point. UNITS Nm Nautical Mile (1Nm = 1.15SM or 1.85km) SM Statute Mile (1SM = 0.87Nm or 1.61km) km kilometer (1km = 0.62SM or 0.54Nm) ft feet (1ft = 0.167ftm or 0.305m)
Page 178: Analytical Index
............. 30 Assigning Page Soft Keys ........... 32 change the SD CARD ..........84 assistance ..............41 Changing the Ship Icon ..........30 Atmospheric Pressure ........88, 176 Channels ..............170 CPN700i and CPN1010i Multimedia Chart Plotters Page 179...
Page 179 Dimensions ..............170 CPN1010i ....11, 12, 104, 152, 161, 162, 168 Direction ..............108 CPN700i ........11, 12, 104, 161, 167 Display ........11, 39, 115, 167, 168 create a Route ............. 67 Display Color ..........34, 35, 38 CREATING A ROUTE ..........
Page 180 HDM ..............167, 169 feet ..............37, 178 HDOP ..............87, 177 FF525 ............. 39, 100, 105, HDT ..............167, 169 110, 152, 158, 159, 170, 176, 178 Heading ............. 87, 109, 177 CPN700i and CPN1010i Multimedia Chart Plotters Page 181...
Page 181 HEIGHT ..............177 LINE COLOR ............... 78 HIGH BOOST PRESSURE ........106 Line Out ............167, 169 High Resolution Bathy Charts ........44 LOADING A FILE ............83 HIGH WATER ............177 Long press ..............32 Highway page ......30, 58, 74, 88, 94, 95 Loop-Back Test ............
Page 182 PDF ......... 11, 141, 142, 143, 146, 147 Release Date ............. 113 Perspective View ............43 remove the SD CARD ..........44 PGN ................167 Remove-Favorite ............140 Photos & Diagrams ............43 replace an SD CARD ..........24 CPN700i and CPN1010i Multimedia Chart Plotters Page 183...
Page 183 replacements parts ............12 SOFT KEYS ..............23 reset the Track ............78 Soft Keys ..............32 reset the Trip Log ..........79, 81 SOG ......85, 87, 96, 108, 111, 177, 178 Resolution ............167, 168 Spanish ............... 35, 136 Respect Draught ............
Page 184 VGA ........ 11, 152, 161, 162, 167, 169 ZOOM 200kHz ............100 VGAC10 adapter cable ..........161 ZOOM 50kHz ............. 100 VHF ....12, 101, 113, 152, 158, 159, 176, 177 ZOOM key ..............16 CPN700i and CPN1010i Multimedia Chart Plotters Page 185...
Page 185 United States: To receive warranty service, the purchaser must deliver the Product, transportation and Insurance prepaid, to STANDARD HORIZON (Marine Division of YAESU USA) - Attention Factory Service - 6125 Phyllis Drive - Cypress, CA 90630, include proof of purchase indicating model, serial number and date of purchase.
Page 186: Declaration Of Conformity
Winnall Close, Winchester SO23 0LB Technical Construction File: Issued by Yaesu Musen Co., Ltd., Tokyo, Japan File No: UK7001111 Drawn up in: Winchester, United Kingdom Date: January 2012 Name and position: PCJ Bigwood, Technical Sales Manager CPN700i and CPN1010i Multimedia Chart Plotters Page 187...
Page 187 Directive 1999/5/EC, with the provisions of Annex III (Conformity Assessment procedure referred to in article 10) Type of Equipment: Chart Plotter for Marine Navigation with internal GPS receiver Brand Name: Standard Horizon Model Number CPN1010i Manufacturer TWS S.r.l...

This manual is also suitable for:

Cpn1010i

Standard Horizon CPN700i Owner's Manual

Introduction

1 General Operation

2 Chart Plotter

3 Connection Manager

4 Internet Browser

5 Media Player

6 Installation

7 Connections

8 Specifications

9 Technical Tests

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Standard Horizon CPN700i

Summary of Contents for Standard Horizon CPN700i
