Summary of Contents for Standard Horizon CP300I

  • Page 1 Color GPS Chart Plotters CP180/CP180i CP300/CP300i Owner's Manual CP180/180i CP300/300i...
  • Page 2 (1) This device cannot cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. STANDARD HORIZON Copyright 2007. All rights reserved. Printed in Italy. OM CODE: S4e/igSH5c_0ww 11.08dA77 & S4e/igSH8wc_0ww 11.12dB33 - 200707 No part of this publication may be reproduced or distributed in any form or by any means, or stored in a database or retrieval system, without prior written permission of the publisher.
  • Page 3 - The GPS Chart Plotter contains dangerous high voltage circuits which only experienced technicians can handle. - STANDARD HORIZON will not be liable for errors contained herein, or for incidental or consequential damages in connection with the performance or use of this material.
  • Page 4 Page GPS Chart Plotters...

  • Page 5: Table Of Contents

    SELECTING LORAN TD OR OTHER COORDINATE SYSTEM ......33 CHANGING THE CHART COLOR ................. 33 SELECTING PAGES USING SOFT KEYS ON CP300/CP300i ......34 CUSTOMIZING THE SOFT KEYS ON CP300/CP300i ......... 34 OTHER SETTINGS IN GENERAL SETUP MENU ..........35 INFORMATION PAGE ....................
  • Page 6 6. MAP FUNCTIONS ...................... 43 MAX FUNCTIONS MENU ..................43 6.0.0 Zoom Type ....................43 6.0.1 Fonts & Symbols ON THE CP300/CP300i ..........43 6.0.2 Perspective View ..................44 6.0.3 Dynamic Nav-Aids ..................44 6.0.4 Safety Status Bar (DSI - Data Safety Indicator) ........45 6.0.5...
  • Page 7 17.0.2 Cartridges ....................92 17.0.3 Serial Ports ....................92 18. SPECIFICATIONS ...................... 93 18.0 CP180/CP180i SPECIFICATIONS ................. 93 18.1 CP300/CP300i SPECIFICATIONS ................. 94 18.2 GPS WAAS SMART Receiver Specifications ............95 19. APPENDIX: TERMS ...................... 97 ANALITYCAL INDEX ...................... 99...
  • Page 8 Page 10 GPS Chart Plotters...

  • Page 9: Introduction

    Congratulations on your purchase of the Standard Horizon GPS Chart Plotter. Whether this is your first GPS Chart Plotter, or if you have other STANDARD HORIZON equipment, the STANDARD HORIZON organization is committed to ensuring your enjoyment of this GPS Chart Plotter.

  • Page 10: Cp180/Cp180I Packing List

    EM016N550 Flush mount template (CP180 ONLY XUCMP0058 GPS WAAS Smart antenna EM023U100 Owner’s Manual EM023U500 Quick Reference Guide 1.1.1 CP300/CP300i Packing List PART CODE ITEM S8002224A External bracket S8002225 Mounting knob with two washers S8002235 Dust cover T9101553 PWR & ACC 1 cable...

  • Page 11: Getting Started

    GPS Chart Plotter especially while under way. After the location is found, attach the mounting base to the area using the supplied hardware. Figure 2.1 - Example of Bracket installation (CP180i on the left side and CP300i on the right side) GPS Chart Plotters...

  • Page 12: Cp180 And Cp300 Flush Mounting

    CP180 AND CP300 FLUSH MOUNTING The CP180 and CP300 are supplied with a flush mount template for the cutout hole and screw holes required to install the GPS Chart Plotter. NOTE Before drilling holes make sure there is enough room to mount the GPS Chart Plotter and there are no obstructions.

  • Page 13: Flush Mounting The Antenna

    Choose a location for the antenna that has a clear view of the sky and is not located within 3 FT of Radar or other transmitting antennas. Ensure there are no major obstructions or fixtures in the immediate proximity to the antenna. The antenna relies on direct “line of sight” satellite reception.

  • Page 14: Connections

    CONNECTIONS The GPS Chart Plotter has connectors that are used to connect to the power supply, GPS Antenna (CP180 CP300 ) optional FF520 50/200kHz BLACK BOX FISH FINDER ONLY and to NMEA devices such as VHF’s, AIS Receivers, digital instruments and autopilots. NOTE The GPS Chart Plotter can send many sentences to external NMEA devices.

  • Page 15: Connection Table For Cp300/Cp300I

    Green Smart GPS NMEA Output Brown Smart GPS NMEA Input Black/Yellow Battery Ground 2.4.1 Connection Table For CP300/CP300i 12VDC Power and NMEA PWR & ACC 1 Cable Pin Wire Color Description Connection Example Additional Comments Black Battery Ground Connect to Battery Ground...

  • Page 16: Connection For Cp180/Cp180I

    NMEA ACC 2 Cable Pin Wire Color Description Connection Example Additional Comments Black Green NMEA Common Common (ground) for NMEA devices Blue Port 4 Input Connect to Output of NMEA device Default is NMEA0183** Brown Port 4 Output Connect to Input of NMEA device Default is NMEA0183 with GLL, RMB, RMC and XTE sentences Gray...
  • Page 17 2.4.2.2 Connection of the FF520, AIS receiver, VHF and Autopilot NOTE Port 2 input and output is used by the optional FF520. In the diagram above you will notice Port 2 Input and Output wires are shown in gray and not used. AIS Setup The CP180 or CP180i has to be setup to be able to receive NMEA information from the AIS receiver.

  • Page 18: Connection For Cp300/Cp300I

    If an AIS receiver is not connected, Port 1 Input can be connected to most DSC VHF’s for position polling. 2.4.3 Connection For CP300/CP300i 2.4.3.1 DC Power Connection 2.4.3.2 Connection a VideoCamera, FF520, AIS receiver, VHF and Autopilot Page 20...

  • Page 19: Battery Connections

    Input and Output both operate at 38400 baud. AIS Setup The CP300 or CP300i has to be setup to be able to receive NMEA information from the AIS receiver. 1. Press [Menu], move the ShuttlePoint knob to highlight SETUP MENU and press [ENT].

  • Page 20: Gps Position On A Vhf Radio

    STANDARD HORIZON has taken this feature one step further, if the GPS Chart Plotters are connected to a STANDARD HORIZON DSC capable VHF, the vessel in Distress or the polled position of the vessel is shown on the display of the GPS Chart Plotter, making it easy to navigate to the location of the vessel.

  • Page 21: Nmea Data Page

    2.11 CP300/CP300i VIDEO INPUT By accessing this menu it is possible to see images on the CP300/CP300i display from an external video signal source, if connected to the CP300/CP300i. It allows the "picture-in-picture" functionality, so a Video Input image can be shown on a window and placed over the Chart, Navigation, Highway, Celestial and NMEA pages image at full screen.
  • Page 22 Video Signal GND Video Signal OUT Figure 2.11.1 - VCR/DVD Input The CP300/CP300i has the capability to select the Video Input in three ways. I. From the menu 1. Press [MENU]. Move the ShuttlePoint knob to highlight SETUP and press [ENT].

  • Page 23: Demo Mode (For Dealer Use)

    2.12 DEMO MODE (FOR DEALER USE) NOTE When the PIP video window is shown, the ShuttlePoint knob can be used to move the position of the PIP window or move the cursor around the chart page. By default the PIP window is controlled by the ShuttlePoint knob.
  • Page 24 Page 26 GPS Chart Plotters...

  • Page 25: Controls And Indicators

    CONTROLS AND INDICATORS NOTE This section defines each control of the GPS Chart Plotter. For instructions, refer to Getting Started and Advanced Settings sections of this Owner's Manual. CONTROLS AND CONNECTIONS The GPS Chart Plotter is controlled by using the keys located on the front panel. These labelled keys are dedicated to specific functions.

  • Page 26: The Cp300/Cp300I Soft Keys

    When pressed shows information on the selected point. 3.0.0 The CP300/CP300i Soft Keys The 6 keys in the bottom of the front panel (hereinafter named Soft Keys) have different functions associated depending on the software: their labels are shown on the screen immediately above the keys (the user can customize the function associated).

  • Page 27: Cursor Vs. Home Mode

    Figure 3.1.0 - Example of Start-Up page on CP180 3. When the GPS Chart Plotter is first turned on it will take some time for the GPS to acquire a fix of your position. Look closely at the GPS Status page and you will see satellites and relative signal strengths.

  • Page 28: Cursor And Menu Selection Speed

    mode. Now as the ship moves through the water the vessels position will be kept in the center of the display. NOTE To change from Cursor mode to Home mode press [CLR]. 3.1.2 Cursor and Menu selection speed The GPS Chart Plotter allows you to control the speed the Cursor moves when the ShuttlePoint knob is pressed.

  • Page 29: Changing The Backlight And Contrast

    3. Move the ShuttlePoint knob to highlight SHIP ICON and press [ENT] or move the ShuttlePoint knob to the right to show the popup window with ship icons. 4. Move the ShuttlePoint knob to select the desired icon and press [ENT] or move the ShuttlePoint knob to the right to select a new icon.

  • Page 30: Adjusting The Time

    ADJUSTING THE TIME The time information supplied by the GPS satellites is in Universal Time Coordinates (UTC or Greenwich England Mean Time). To change the GPS Chart Plotter to read the correct time, first you must figure out the offset and if it is daylight savings time. For example on the West coast of the United States or Pacific Standard Time the offset needed would be –08:00 or –07:00 for daylight savings time, Eastern Standard Time –05:00 or –04:00 for daylight savings time.

  • Page 31: Selecting Loran Td Or Other Coordinate System

    make the GPS Chart Plotter shows the correct time. 7. Move the ShuttlePoint knob to the “+”. Move the ShuttlePoint knob up or down to change to the desired offset. 8. Next move the ShuttlePoint knob to the right to select Hours and move the ShuttlePoint knob up or down to change the hour.

  • Page 32: Selecting Pages Using Soft Keys On Cp300/Cp300I

    SELECTING PAGES USING SOFT KEYS ON CP300/CP300i The Soft Keys located under the LCD on the CP300 and CP300i are used to select the pages quickly without the need to go into the menu. The default pages are VIDEO, CHART, NAV, HIGHWAY, CELESTIAL and NMEA DISPLAY.

  • Page 33: Other Settings In General Setup Menu

    Key can be customized to show 50 or 200kHz full page, 50 or 200kHz Chart/Fish split screen and zoom screens. Figure 3.6 - Window options of the selected Soft Key on CP300/CP300i 1. To change, momentarily press any of the Soft Keys, then press and hold the Soft Key you want to customize.

  • Page 34: Information Page

    CURSOR SPEED Selects the preferred speed among Low, Medium and High for the cursor in the Chart page and within the menu. MEASURE DISTANCE When this function is turned on allows a distance to be measured between two points using the ShuttlePoint knob and [ENT]. WINDOWS SETUP This menu selection allows the data windows to be customized on the Chart and Navigation pages.

  • Page 35: Using Find Services & More Function

    USING FIND SERVICES & MORE FUNCTION With a C-MAP NT /MAX C-CARD installed the GPS Chart Plotter allows you to search for a Port Service, Port, Tide Stations, Wrecks, Obstructions, POIs, Lakes, User Points, or GPS Coordinates. PORT SERVICES With a C-MAP NT /MAX C-CARD installed, the GPS Chart Plotter can find Port Services contained on the map.

  • Page 36: Info On Lakes

    INFO ON LAKES 4.2.0 Quick Info On Lakes Upon viewing the chart of a lake, you will click on to query the available information immediately displayed with many details. For example, see the following picture: Figure 4.2.0 - Example of Lakes info When the cursor is placed over the icon, the icons of the available services are shown: Figure 4.2.0a - Quick Info: available services If you press [ENT] all available information about the cartographic point under the cursor...
  • Page 37 To see the "Fishing" object press [MENU] (when the "Fishing" object is highlighted). On the screen appears: Figure 4.2.1a - Example of picture associated to the Fishing object GPS Chart Plotters Page 39...
  • Page 38 Page 40 GPS Chart Plotters...

  • Page 39: C-Map Max Overview

    C-MAP MAX OVERVIEW INSERTING THE C-CARD Hold the C-CARD by the long inclined side so that you can see the C-MAP label. Figure 5.0 - Inserting C-CARD Open the door, gently push the C-CARD into the slot: push the C-CARD in as far as it will go, then close the door.
  • Page 40 · Dynamic Elevation Data (optimized palettes for GPS Chart Plotters; includes new NOAA palette) · Perspective View ("Real World" perspective view of the chart, updated real-time during navigation) MAX and NT/NT C-CARD coexistence · When NT data and MAX data cover different areas, the GPS Chart Plotter receives data from both charts (depending on the current position).

  • Page 41: Map Functions

    6.0.1 Fonts & Symbols ON THE CP300/CP300i On MAX charts it is possible to set the size of all names and symbols drawn on the charts, selecting between Normal size (the regular characters size) and Large size.

  • Page 42: Perspective View

    5. Move the ShuttlePoint knob to select the selection and press [ENT]. 6. Press [CLR] until the menu disappears or an easier method is to move the ShuttlePoint knob to the left a few times. NORMAL size LARGE size Figure 6.0.1 - Example of Normal size (on the left side) and Large side (on the right side) settings 6.0.2 Perspective View Chart data may be projected in perspective mode during navigation.

  • Page 43: Safety Status Bar (Dsi - Data Safety Indicator)

    When Dynamic Nav-Aids option is set to On, when the flashing light is Off, or when fix position is out of the sector, the light color is displayed by using a faint light color. To activate this function follow the procedure below: 1.

  • Page 44: Currents Prediction

    3. Move the ShuttlePoint knob to highlight CURRENTS PREDICTION and press [ENT] or move the ShuttlePoint knob to the right. 4. A window is shown on the low-left side of the chart. On the CP300/CP300i, press [S to set the date and time manually, and [I ]/[D ] to decrease/increase time;...

  • Page 45: How To Show The Pictures Or Diagrams Of A Multimedia Object

    Figure 6.0.6a - Example of Quick Info on MULTIMEDIA object Press [I ] on the CP300/CP300i or press [ENT] on the CP180/CP180i for 1 second to MAGE display the image on the screen; press [E...

  • Page 46: Enhanced Port Info

    6.0.7 Enhanced Port Info MAX charts include additional port services that were not present before. Additional attributes of Port Areas and Port Marinas have been included (Location, Country, Region, State, Harbour master telephone number etc.). Page 48 GPS Chart Plotters...

  • Page 47: Creating Marks

    Lat/Lon of the Mark. 3. If the position is incorrect on the CP180/CP180i press [ENT], select EDIT using the ShuttlePoint knob and press [ENT]. On the CP300/CP300i, press [E ] that will allow you to change the position, Mark name, icon type and color of the icon.

  • Page 48: Deleting A Mark Or Waypoint

    Move the cursor over the Mark or Waypoint to delete. On the CP180/CP180i press [ENT], select DELETE using the ShuttlePoint knob and press [ENT]. On the CP300/CP300i, press ]. A Warning popup window will be shown. Select YES and press [ENT].

  • Page 49: Marks/Waypoints List

    Figure 7.1.1a - Moving Mark or Waypoint (II) MARKS/WAYPOINTS LIST The MARKS/WPTS List shows all the Marks and Waypoints that have been stored into the GPS Chart Plotter. This page also allows you to: ICON Allows sorting by icon type FIND Searches through the Marks or Waypoints to find a point by name using the ShuttlePoint knob LOCATE...

  • Page 50: Creating A New Mark With The User Points List

    CREATING A NEW MARK WITH THE USER POINTS LIST NOTE This function is very useful if you have a list of Marks that you want to enter into the GPS Chart Plotter. 1. Press [MENU]. Move the ShuttlePoint knob to highlight USER POINTS and press [ENT]. 2.

  • Page 51: Goto Mark

    6. The GPS Chart Plotter is in Cursor mode, to switch to Home mode press [CLR] so the vessel will stay in the center of the page. 7. On the CP300/CP300i two Soft Keys are also shown that allow you to quickly switch to the HIGHWAY page or to stop navigation.
  • Page 52 Page 54 GPS Chart Plotters...

  • Page 53: Man Over Board (Mob) Function

    2. You will notice a MOB Mark will be on the Chart page and all navigation is referring back to this point. 3. On the CP300/CP300i: If the cursor is moved over the MOB Icon, the popup windows over Soft Keys will be shown allowing quick access to the Navigation or Highway pages.
  • Page 54 Page 56 GPS Chart Plotters...

  • Page 55: Routes

    ROUTES The GPS Chart Plotter has the capability to store, for CP180/CP180i: 20 Routes with a maximum of 30 Waypoints each, for CP300/CP300i: 50 Routes with a maximum of 30 Waypoints each. A Route can consist of Waypoints or Marks. The difference is when a Route is made using Waypoints and the Route is deleted the Waypoints are also deleted.

  • Page 56: Making Additional Routes

    Figure 9.0 - Route Report 11. When finished press [ENT] to save. 12. Press [CLR] to show the Chart page. MAKING ADDITIONAL ROUTES To create another Route the GPS Chart Plotter must be told that you want to create a second Route.

  • Page 57: Inserting A Waypoint Into A Route

    Point knob to the right. A popup window will be shown. 9. Move the ShuttlePoint knob up/down to change the characters and left/right to select a different character in the Routes Name. 10. When finished press [ENT] to save. 11. Press [CLR] to show the Chart page is shown. INSERTING A WAYPOINT INTO A ROUTE Place the cursor on the navigation line between two points and press [ROUTE].
  • Page 58 Page 60 GPS Chart Plotters...

  • Page 59: Tracks

    10. TRACKS The GPS Chart Plotter has the capability to store 5 individual tracks and record up to 3000 Track Points. Before using the Track function you will need to setup the Track function that suits your boat. The Track function tracks your vessels location as it moves through the water. The Track function can be setup to lay down a Track for a predetermined time or distance interval.

  • Page 60: Saving And Starting A New Track

    Figure 10.0 - Tracking 10.0.0 Saving and starting a new Track A Track is automatically saved to memory. To start a new Track: 1. Press [MENU]. Move the ShuttlePoint knob to highlight USER POINTS and press [ENT]. 2. Move the ShuttlePoint knob to highlight TRACK and press [ENT]. 3.

  • Page 61: Resetting The Trip Log

    4. Press [CLR] or move the ShuttlePoint knob to the right until the selected page (Chart, Navigation, Highway or NMEA Data Page) is shown. 10.1.0 Resetting the Trip Log Select the page with TRIP LOG in one of the data windows as setup in the “Using the TRIP LOG”...
  • Page 62 Page 64 GPS Chart Plotters...

  • Page 63: User C-Card

    GPS Chart Plotter's memory. The User C-CARD is similar to a back up disk used with a PC, in case you have to clear your GPS Chart Plotter's memory, or if you would like to transfer Waypoint, Track and Route information from one STANDARD HORIZON GPS Chart Plotter to another. 11.0...

  • Page 64: Loading A File

    2. Press [MENU]. Move the ShuttlePoint knob to highlight USER POINTS and press [ENT] 3. Move the ShuttlePoint knob to highlight USER C-CARD and press [ENT] 4. A screen will appear. Move the ShuttlePoint knob to the left to highlight SAVE and press [ENT].

  • Page 65: Pages

    Figure 12 - Screen display pages The pages can selected in the following way: Selection by MENU This function is available on the CP180/CP180i and CP300/CP300i. 1. Press [MENU]. The following page is shown on the screen: Figure 12a - Main Menu 2.

  • Page 66: Chart Page

    Figure 12b - Screen display pages (by Soft Keys) on CP300/CP300i 12.0 CHART PAGE The Chart page is the main page of the GPS Chart Plotter. From this page the user can zoom in/out, pan around the chart, show information about cartographic objects, see the exact vessel position with the COG and SOG, place points, GOTO a destination point, show Track history etc.

  • Page 67: Additional Functions On Chart Page

    1. To change, press [MENU]. Move the ShuttlePoint knob to highlight SETUP MENU and press [ENT]. 2. Move the ShuttlePoint knob to highlight GENERAL SETUP and press [ENT] or move the ShuttlePoint knob to the right. 3. Move the ShuttlePoint knob to highlight WINDOW SETUP and press [ENT] or move the ShuttlePoint knob to the right.

  • Page 68: Marine Settings

    Setting Full Medium RADAR Tides Custom (Default values) Place Names Name Tags Nav-Aids & Light Sectors No Sector No Sector No Sector Attention Areas Tides & Currents Seabed Type Ports & Services Tracks & Routes Depth Range Min 0 Ft 0 Ft 0 Ft 0 Ft...

  • Page 69: Depth Settings

    12.0.5 Depth Settings To control the display on the map of the depth informations. Depth Range Min : Sets the minimum depth limit to show Depth Sounding, Bathymetric Lines and Depth Area. The default setting is 0 Feet. Depth Range Max : Sets the max depth limit to show Depth Sounding, Bathymetric Lines and Depth Area.

  • Page 70: Customizing The Data Windows

    Rocks The default setting is Icon. Sets Off/Icon/Icon+Depth* the displaying of the Rocks. Obstructions The default setting is Icon. Sets Off/Icon/Icon+Depth* the displaying of the Obstructions. Diffusers The default setting is Icon. Sets Off/Icon/Icon+Depth* the displaying of Diffusers. Wrecks The default setting is Icon. Sets Off/Icon/Icon+Depth* the displaying of Wrecks.

  • Page 71: Highway Page

    Fix position Time 3 Speed Over Ground Course Over Ground Compass Rose Figure 12.2 - Navigation Data page with Compass Rose Compass Tape Fix position Time Time To Go Speed Over Ground Distance to Destination Course Over Ground Bearing to Destination Figure 12.2a - Navigation Data page with Compass Tape 12.3 HIGHWAY PAGE...

  • Page 72: Celestial Page

    12.4 CELESTIAL PAGE This page is useful for boaters that are concerned about the height of the water under a bridge or by fisherman that wish to know the tide and moon phase of a specific date. Changing date 1. Press [ENT] and a popup window will be shown. 2.

  • Page 73: Nmea Display Page

    1a. On the CP180/CP180i, press [MENU]. Move the ShuttlePoint knob to highlight NMEA DISPLAY and press [ENT]. 2. The CP300/CP300i can use step 1a, and from the factory the right most Soft Key is programmed for direct access. Press this key two times to show the NMEA Display page.

  • Page 74: Nmea Depth, Wind Speed, Temp And Sog Trend

    STANDARD HORIZON VHF Marine Radios with Digital Selective Calling are able to be interfaced with the GPS Chart Plotter which feeds GPS data to the VHF and listens for DSC calls from the VHF. By connecting a few wires between the STANDARD HORIZON VHF and the GPS Chart Plotter it will receive: 1.

  • Page 75: Dsc Distress Call

    Vessel in Distress and also allows for easy navigation to the vessel. 12.9.2 Position Request STANDARD HORIZON VHF radios can transmit a DSC call to other equipped Vessels with a DSC VHF or request this radio transmit the GPS position. When this position is received the STANDARD HORIZON VHF radio sends the information to the GPS Chart Plotter which displays the GPS position of the vessel on the Chart page.
  • Page 76 Page 78 GPS Chart Plotters...

  • Page 77: Advanced Settings

    The CP180 has 2 NMEA inputs and 3 NMEA outputs, while the CP180i has 1 NMEA inputs and 2 NMEA outputs. The CP300 has 4 NMEA inputs and 5 NMEA outputs, while the CP300i has 3 NMEA inputs and 4 NMEA outputs. The NMEA outputs can be configured to send specific NMEA messages.

  • Page 78: Compass

    To use the TD Coordinate System the user must setup the Chain and Pair information of the TD’s. If you do not know this information, refer to paper charts that show the Chain and Pair information. ASF1/2 : Additional Secondary phase Factor (TD Coordinate System) Correction to TD1/2 values which can be inserted by the user to take in account the additional signal propagation delay aver a mixed land/seawater path compared to on all- seawater path.
  • Page 79 When any of the objects checked are found for the first time, the GPS Chart Plotter shows a pop up window to alert the user of the possible danger. The name of each new dangerous object found is reported in the warning window. In the Grounding Alarm Report page the relative item has a tick marker next to it, to identify the dangerous object currently detected.
  • Page 80 Page 82 GPS Chart Plotters...

  • Page 81: Ais

    14. AIS AIS is an Automatic Identification System. It has been introduced to improve the safety of navigation by assisting in the efficient operation of ship-to-ship location reporting and VTS applications. The system should enable operators to obtain information from the ship automatically, requiring a minimum of involvement of ship’s personnel, and should have a high level of availability.

  • Page 82: Ais Menu

    utes. The presentation will be a flashing black triangle with a cross through. ♦ Activation Range: Range around your boat where targets become active. AIS target become active within this range. Activation Range should be greater than CPA Limit by definition. NOTE A target is removed from the screen if data is not received for 10 minutes.

  • Page 83: Quick Info On Ais Target

    Where: n = for CP180/CP180i Port 1/Port 2*/Port 3, for CP300/CP300i Port 1/Port 2*/Port 3/Port4/ Port5 NOTE* For CP180i and CP300i there is not the selection for the Port 2. 14.3 QUICK INFO ON AIS TARGET By placing the cursor over a AIS Target icon using the ShuttlePoint knob, the following information is displayed: ♦...
  • Page 84 Page 86 GPS Chart Plotters...

  • Page 85: C-Map Weather Service

    15. C-MAP WEATHER SERVICE C-MAP Weather Service is an innovative meteorological forecasting system with the ability to visualize the weather forecast, overlaying it on cartography. The weather data is held on C-MAP’s weather server, which can be accessed via a C-COM modem connected to the GPS Chart Plotter or by using the C-MAP personal Suite saving the weather data on a User C-CARD.

  • Page 86: Copy From User C-Card

    Area of coverage of Cursor is locked to the downloaded data is gray area. located by default with Moving the cursor also its centre on the moves the gray area cursor position allowing locating it over the area where the user wants to download the Meteo forecast.

  • Page 87: Trouble Shooting

    16. TROUBLE SHOOTING The GPS Chart Plotter does not turn On. The voltage or the polarity may not be correct. Make sure that the correct voltage (10-35 volt dc) is present. Check also that the polarity is correct. The GPS Chart Plotter does not get a valid fix. The GPS WAAS Smart Antenna may not be in a open sky position or the antenna cable may not be properly connected.
  • Page 88 Page 90 GPS Chart Plotters...

  • Page 89: Technical Tests

    17. TECHNICAL TESTS 17.0 SYSTEM TEST If you have connected your GPS Chart Plotter according to the instructions, and chosen the proper menu selection for your device, and are still having problems with your GPS Chart Plotter, the extended auto-test should help determine the problem. Make sure the GPS Chart Plotter is turned Off.

  • Page 90: Cartridges

    17.0.2 Cartridges To check the C-CARD and its connector. Internal Data Base Test To test the WorldWideBackground. C-CARD Test To test the C-CARD. There are the possible situations: 1. if there is a C-CARD inserted in the slot and there is not a malfunction, the name of the C-CARD zone and the message "OK"...

  • Page 91: Specifications

    18. SPECIFICATIONS 18.0 CP180/CP180i SPECIFICATIONS Power Consumption CP 180i: 520mA max @12V CP 180 : 460mA max @12V WITH XTERNAL CONNECTED CP 180 : 410mA max @12V WITHOUT XTERNAL CONNECTED Power supply : 10-35 Volt DC Interface : Input/Output Interface NMEA-0183 Display : TFT Color LCD sunviewable technology...

  • Page 92: Cp300/Cp300I Specifications

    HDT, RMC, VHW, VTG, DPT, DBT, MTW, VWR, VWT, TLL, WPL, RTE. REMOVABLE Grip 152.4 [6"] REMOVABLE Mounting Bracket 98.6 [3.9"] GRAY parts are present 37 [1.5"] 37 [1.5"] ONLY on CP300i 251 [9.9"] 4.1 [0.2"] Figure 18.1 - CP300/CP300i Dimensions [mm/inch] Page 94 GPS Chart Plotters...

  • Page 93: Gps Waas Smart Receiver Specifications

    18.2 GPS WAAS SMART RECEIVER SPECIFICATIONS This GPS WAAS Smart Receiver is based on a ultimate GPS engine that delivers accuracy better than three meters by decoding the GPS correction signals from the satellite-based WAAS (Wide Area Augmentation System). The GPS engine, interface electronics and the passive antenna are enclosed inside the water-proof plastic housing.
  • Page 94 Page 96 GPS Chart Plotters...

  • Page 95: Appendix: Terms

    19. APPENDIX: TERMS ALT (Altitude) – Shows the Altitude of the vessel. APP Wind DIR SPD (Apparent Wind Direction) – Shows the Apparent Wind Direction when a external wind instrument with NMEA is connected. APP Wind SPD (Apparent Wind Speed) – Shows the Apparent Wind Speed when a external wind instrument with NMEA is connected.
  • Page 96 Position Request – Marine DSC VHF Function of transmitting a GPS position to another Marine DSC VHF. When GPS Chart Plotter is connected to STANDARD HORIZON GPS the position of another vessel is shown on the Chart page. SPEED – Shows the Speed Thru the Water when a Digital Speed Log is connected.

  • Page 97: Analitycal Index

    ANALITYCAL INDEX CP300 ........11, 14 Adjusting Time ........32 CP300/300i ... 12, 17, 20, 34, 43, AIS ............ 83 57, 67, 94 Alarms ........79, 80 Creating a Route ....... 57 ALT ........... 97 Currents Prediction ......46 Altitude ........35, 97 cursor ..........
  • Page 98 FLUSH MOUNTING ......14 MAX OVERVIEW ......41 Flush Mounting Antenna ....15 MEASURE DST & BRG ....36 Fonts & Symbols ....... 43 Memory ........93, 94 MENU ..........27 GOTO ..........27 MIXING LEVELS ....... 45 Goto Cursor ........52 MOB ...........
  • Page 99 Resolution ........93, 94 Track Points ......61, 93, 94 Reverse Route ........59 Tracks + Routes ........ 70 Roads ..........72 TRIP LOG ........62, 98 Rocks ......... 71, 72 TROUBLE SHOOTING ..... 89 Route ......28, 49, 93, 94 TRU Wind DIR SPD ......
  • Page 100 STANDARD HORIZON cannot be responsible in any way for ancillary equipment not furnished by STANDARD HORIZON which is attached to or used in connection with Products, or for the operation of the Product with any ancillary equipment, and all such equipment is expressly excluded from this warranty.
