Connect The Service Processor Serial Management Port - Sun Oracle SPARC T5120 Installation Manual

Note – When you are finished connecting the cables to the server, ensure that the
server can slide smoothly in and out of the rack without binding or damaging the
cables. See the section,
page
This topic contains the following tasks:
"Connect the Service Processor Serial Management Port" on page 38
■
"Connect the Service Processor Network Management Port" on page 40
■
"Connect the Ethernet Network Cables" on page 41
■
"Connect the AC Power Cable to the Server" on page 41
■
Related Information
"Verify the Operation of the Slide Rails and the CMA" on page 35
■
"Secure the Server Cables in the CMA" on page 42
■
Connect the Service Processor Serial Management
Port
The service processor serial management port is marked SER MGT. This port is the
farthest left RJ-45 port on the rear panel.
Note – The cable and DB-9 RJ-45 adapters are for the host serial port, and not for the
server SER MGT port.
38 SPARC Enterprise T5120 and T5220 Servers Installation Guide • October 2010
"Verify the Operation of the Slide Rails and the CMA" on
35.
