Install The Cable Management Arm - Sun Oracle SPARC T5120 Installation Manual

Note – The CMA includes velcro straps to secure the cables inside the CMA. Do not
install the velcro straps until you install the CMA, connect the cables, and place the
cabling inside the CMA as described in the following procedures.
"Install the Cable Management Arm" on page 31
■
"Verify the Operation of the Slide Rails and the CMA" on page 35
■

▼ Install the Cable Management Arm

Caution – Support the CMA during this installation. Do not allow the assembly to
hang by its own weight until it is secured by all three attachment points.
1. Remove the tape from the CMA rail extension (on the left of the CMA) and
remove the CMA rail extension.
2. Attach the CMA rail extension to rear left slide rail.
At the rear of the rack, plug the CMA rail extension into the end of the left sliding
rail assembly. The tab at the front of the rail extension clicks into place.
Installing the SPARC Enterprise T5120 and T5220 Servers 31
