Note – The procedures in this chapter are the same for both the 1U and 2U servers.
The illustrations show a 2U server only as an example.
The rackmounting kit (same for both 1U and 2U servers) contains two slide rail
assemblies, which can be installed on either the right or left side of the rack. A slide
rail assembly consists of two parts, a slide rail and a removable mounting bracket.
The slide rail attaches to the rack posts. The mounting bracket attaches to the server
chassis. See
information about slide rail assemblies.
"Install the Slide Rail Assemblies" on page 22
■
"Insert and Lock the Server in the Rack" on page 29
■
Related Information
"Slide Rail Assembly Notes for Both Servers" on page 15
■
"Install the Slide Rail Assemblies" on page 22
■

▼ Install the Slide Rail Assemblies

1. Pull both mounting brackets completely out of their respective slide rails.
a. Simultaneously press and hold the upper and lower lock buttons of the slide
22 SPARC Enterprise T5120 and T5220 Servers Installation Guide • October 2010
"Slide Rail Assembly Notes for Both Servers" on page 15
rail lock.
for more
