d. Verti: the number of divisions that divide the Y-axis.
6. Channel frame: these settings are used to configure the color of each line.
a. Channel: select the particular channel that you wish to change color properties.
b. Pen property frame:
i. Color: Select the particular color for the channel
ii. Width: Select the width of the line. Note: if a value other than 1 is selected for the width, the
style option is not available.
iii. Style: determines the style of the line displayed when width is set to 1.
7. Shape tab: used to configure the text labels and constant values assigned to each State.
