Introduction
Numeric Data
ASCII Input
ASCII Data
Moving Shapes
Animation
Indirect Window
Direct Window
Alarm Displays
Alarm Bar
Data Transfer
(triggered)
Data Transferred
(time-based)
Event Displays
Data Sampling
(Data Logging)
Alarm/Event Log
Trend Displays
Bar Graph
Displays
Meter Displays
Recipe Transfer
System
Message
PLC Control
History Data
Display
Displays a number stored in a PLC register.
Displays ASCII characters stored in a PLC register. Characters can be changed using an
alphanumeric keypad.
Displays ASCII characters stored in a PLC register.
Creates a multi-state graphics object, which changes state (picture) and position on the screen
according to a value in a PLC register.
Creates a multi-state graphics object, which changes state (picture) on the screen according to a
value in a PLC register. The positions on the screen are predefined.
Configures the OIT to monitor PLC data registers to display for a specific window popup by a
PLC word address
Displays a Window based on a bit in a PLC register.
Creates alarms to display alarms sent from the Alarm/Event Log Object.
Displays alarms detected by the Alarm/Event Log Object on a single horizontal scrolling line.
Transfers data to the specified PLC registers based on a touch or PLC bit status.
Transfers data to the specified PLC registers on a timed basis.
Displays messages detected in the Alarm/Event Log and can acknowledge the message(s).
Stores data for trending and archiving.
Contains the data for detecting alarm conditions.
Creates a trend graph. Samples data in a single or multiple 16-bit PLC register and plots the
data on a time graph.
Creates a bar graph with alarm monitoring.
Creates a scale meter.
Transfers data to the specified PLC registers.
Customizes the content of system-generated messages.
Configures the OIT to monitor PLC data registers to display full window screens.
Displays historical data in a tabular format.
