Rep re sent ing Data with Graphic Ob jects
Top frame:
Use label: click to enable the label feature
Use label library: clicking this checkbox allows you to select a label tag from the label library. Note: this feature
is not available until you first create label tags in the Label Library.
oLabel tag: Select from the drop-down box which label tag you wish to use.
oLabel Library... button: click to go to the Label Library to add/edit tags.
Language: this appears if you are using the Label Library. Allows you to see the text for that
particular language and change the font size but you cannot edit this from this tab- you must go to the
Label Library. Note: for more information on using Languages, see Chapter 9: Creating and Using
Databases and Languages
State: use this drop-down box or the buttons adjacent to see and adjust the parameters for the text for that
particular state.
Attribute frame:
Font: select type of font
Color: select color for text
Size: select font size
Align: this is how the text will align in relation to the size of the object. Options are left, center, or right text
alignment.
Blink: blinks the text. Options are none, 1 second, and 0.5 seconds.
Italic: to show text in italics. Note: Although selectable, this option is not available for every font.
Underline: to show text in underline. Note: Although selectable, this option is not available for every font.
Duplicate these attributes to
o Every state button: When clicked, EZware-5000 will automatically copy the attributes to every state.
o Every language button: copies attributes to every language. Note: this button is only available when a label
tag is used.
o All: copies for all states and all languages. Note: only available when label tag is used
Movement frame:
Direction: a special effect that allows you to create a label that will scroll across the object in the direction
selected: Left, Right, Up, or Down.
o Speed: determines the relative scrolling speed (slowest setting on the left)
o Continuous: if checked, the text will repeat itself continuously
