NTI SERVER ENVIRONMENT MONITORING SYSTEM
Options:
Dual Power – ENVIROMUX with two power connections for optional extra power source connection (see page
15) - add "-DP" to the model number (i.e. ENVIROMUX-SEMS-16-DP)
DC Power - to install the ENVIROMUX in a Telecom environment (see page 16). Add -48V to the model
number (i.e. ENVIROMUX-SEMS-16-48V)
* Converter accepts 36~72VDC (48VDC nominal), positive or negative polarity.
* 3-pole screw terminal for connecting 48V input

MATERIALS

Materials included with this kit:
1- ENVIROMUX-SEMS-16 Server Environment Monitoring System
4- #10-32 x 3/4" pan head screws and #10-32 cage nuts (server cabinet mounting hardware)
1- Power Cord- country specific (2 power cords for model ENVIROMUX-SEMS-16-DP)
1- CD containing a pdf of this owners manual
1- Quick Start Guide
1- Rack mount kit
Materials required for connection but not supplied:
Cables required for connection:
•
DB9 male to female standard serial cable wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc..)
Cat5 for RS485 sensors with RJ45 connectors wired to the TIA/EIA-568B standard (see page 72 for
specifications)
ENVIROMUX-2W-xx 2-wire sensor cables (page 5) for dry contact sensors
Cables required for Expansion via Cascading:
•
Cat5 cable with RJ45 connectors wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc..)

Available Sensors

ENVIROMUX-STS Temperature Sensor
* Applications from 32°F to 122°F (0ºC to 50ºC)
* High resistance to external influences on the cable due to digital output signal
* Accurate to within ±2°F (±1ºC)
* Includes mounting hardware
* Connects to RJ45 sensor ports only
* Maximum CAT5 cable length: 1000 ft.
ENVIROMUX-SHS Humidity Sensor
* Applications from 20% to 80% relative humidity at temperatures between 0ºC and 40ºC.
* High resistance to external influences on the cable due to digital output signal
* Accurate to within ±5% relative humidity
* Includes mounting hardware
* Connects to RJ45 sensor ports only
* Maximum CAT5 cable length: 1000 ft.
ENVIROMUX-STHS Temperature/Humidity Combination Sensor
* Applications from 32°F to 122°F (0ºC to 50ºC) and 20% to 80% relative humidity
* High resistance to external influences on the cable due to digital output signal
* Accurate to within ±2°F (±0.1ºC) and ±5% relative humidity
* Includes mounting hardware
* Connects to RJ45 sensor ports only
* Maximum CAT5 cable length: 1000 ft.
(Sold separately) :
