Figure 1- Typical Application - Network Technologies ENVIROMUX-SEMS-16 Installation And Operation Manual

NTI SERVER ENVIRONMENT MONITORING SYSTEM
Sensors & Digital Inputs
Humidity
-xx
Temperature
°C
ENVIROMUX-SEMS-16
Terminal
Vibration
Door
Liquid
Contact
Detection
DIGITAL IN
RJ45 SENSORS

Figure 1- Typical Application

Output Devices
Keypads
Door Locks
OUT
BEACON SIREN
OUTPUT RELAYS IN CONSOLE
Network
Management
Station
8
GSM Modem
AUX AUX
ETH
LAN
Camera
