Network Technologies ENVIROMUX-SEMS-16 Installation And Operation Manual page 11

NTI SERVER ENVIRONMENT MONITORING SYSTEM
ENVIROMUX-IMD-MW Mini Infrared Motion Sensor
* Registers movement in the area covered
* Condition display via LED
* Provides substantial immunity to false alarms caused by environmental disturbances
* Pulse count or single shot triggering
* Good RFI protection
* Screw terminal connector on sensor
* Connect to RJ45 or digital input sensor ports
* Dimensions WxDxH (in.): 2.2x1.2x2.9 Surface or corner mounting
* Maximum cable length 1000 ft.
ENVIROMUX-IMD-CM Ceiling Mount Motion Sensor
* Detects movement across the detection field
* 360° detection pattern
* 113° conical detection angle from ceiling
* 36 foot diameter protection when mounted 12 feet high
* Provides substantial immunity to false alarms caused by environmental disturbances
* Pulse count or single shot triggering
* Connect to RJ45 or digital input sensor ports
* Good RFI protection
* Screw terminal connector on sensor
* Maximum cable length 1000 ft.
ENVIROMUX-SDS Smoke Detection Sensor
* Warning of smoke
* Includes mounting hardware
* Connect to RJ45 or digital input sensor ports
* Supports CAT5/5e/6 UTP or STP cables
* Screw terminal connector on sensor
* Photoelectric smoke detector
* Built-in heat element: rated for 135°F.
* Maximum cable length: 1000 ft.
ENVIROMUX-S60VDC Voltage Detector Converter
* Monitors up to two DC voltage sources
* Voltage range: 0VDC-60VDC or -60VDC-0VDC
* 5-postion terminal block for sensor attachment
* Includes mounting ears
* Connects to RJ45 sensor ports only
* Maximum CAT5 cable length: 1000 ft.
ENVIROMUX-S420MA Current Sensor
* Monitors up to two 4-20mA sensors
* Supports ISA Type 2, ISA Type 3 and ISA Type 4 sensors
* 8-postion terminal block for sensor attachment
* Provides 18VDC, 25mA for each sensor
* Includes mounting ears
* Connects to RJ45 sensor ports only
* Maximum CAT5 cable length: 1000 ft.
NOTE: A maximum of eight (8)
ENVIROMUX-S60VDC and/or
ENVIROMUX-S420MA may be
connected to an ENVIROMUX-
SEMS-16, 4 on RJ45 Sensor
ports 1-8, and 4 on RJ45 Sensor
ports 9-16.
4
