NTI SERVER ENVIRONMENT MONITORING SYSTEM
ENVIROMUX-ACLM-V Line Voltage Monitor
* Monitors up to two AC voltage sources
* Voltage range: 50~250VAC @ 47~63Hz
* IEC 320 C14 inlets for cord attachment
* Includes mounting ears
* Connects to RJ45 sensor ports only
* Maximum CAT5 cable length: 1000 ft.
ENVIROMUX-ACLM-P Line Voltage,Frequency, and Power Monitor
* Monitors a single AC voltage source and device power consumption
* Voltage range: 50~250VAC @ 47~63Hz
* Current rating: Devices up to 12A (ACLM-P12) or 8A (ACLM-P8)
* IEC 320 C14 inlet for cord attachment
* IEC 320 C13 outlet for load attachment
* Configurable power disconnect for load
* Includes mounting ears
* Connects to RJ45 sensor ports only
* Maximum CAT5 cable length: 1000 ft.
ENVIROMUX-2W-xx Sensor Cables
* 2-wire sensor cable
* Used to connect dry contact sensors to the ENVIROMUX
* Available lengths (ft.): 3/6/10/25/50/100
Available Accessories (sold separately)
ENVIROMUX-ACK Digital Keypad
* Two relay outputs controlled by two groups of independent user codes
* Output 1: 5 Amp relay for door strike
* Output 2: 1 Amp relay for other control applications
* Normally closed and normally open dry contacts for both output relays
* LED indicators for operation status and system status
* Terminal block for all external connections
* Single lock or inter-lock operation
* Standard single gang mounting box
* Built-in tamper switch
* Operate with fail-safe or fail-secure locking device
* Door open announcer
* Non-volatile memory in case of power failure
ENVIROMUX-RKS Key Station
* Remote key station designed for security system ON-OFF control applications
* Built with universal connection terminals; can be used freely with most security systems
* Provides momentary contact with spring return
* Standard single gang mounting box
* Built-in tamper switch
* Built-in connection terminals
* For security system and door strike applications
* Dimensions WxDxH (in.): 1.7x 2.9x4.6
