NTI SERVER ENVIRONMENT MONITORING SYSTEM

Settings-Serial Port Setup

Figure 38- Serial Port Setup Page

The ENVIROMUX serial port (labeled "Console" ) must be setup to communicate with the terminal (page 13). Under
Administration ->Settings-> Serial Port, set the baud rate and format to the same settings as those of the port on the connected
terminal.

Users-Root

Under Administration-> Users->Root, the root user (or any user with administrator rights) can change the root password and
configure how the root user will receive alert messages. Users with administrative rights can change all configuration settings
except for the root user name.

Figure 39- Edit user profile for root user

39
