NTI SERVER ENVIRONMENT MONITORING SYSTEM
ENVIROMUX-LDS-x Liquid Detection Sensor
* For warning of flooding
* Detects any conductive liquid covering at least 5/8" diameter and 1/8" deep
* Liquid sensor cable lengths: 3, 7, 10, or 25 feet (ENVIROMUX-LDS-3/7/10/25)
* Connects to RJ45 sensor ports only
* Maximum CAT5 cable length: 1000 ft.
ENVIROMUX-VSS Vibration Sensor
* For registering movement and shocks
* Adjustable sensitivity
* Includes mounting hardware
* Connect to RJ45 sensor ports only
* Screw terminal connector on sensor for connection of CAT5/5e/6 UTP or STP cable
* Maximum CAT5 cable length: 1000 ft.
ENVIROMUX-M-DCS Door Contact Sensor
* Monitors access with a magnetic bridge sensor
* Screw terminals for 2-wire interface
* Wide actuating gap - approximately 1 inch
* Normally closed circuit connection
* Dimensions WxDxH (in.)- 0.5x0.5x2 (Switch), 0.5x0.5x2 (Magnet)
* Maximum cable length: 1000 ft.
ENVIROMUX-GBS Glass Break Detection Sensor
* Emits flashing red light when activated
* Flash Rate: 80 to 120 per minute at 6VDC; 60 to 80 per minute at 12VDC
* Screw terminal connector on sensor
* 2-wire interface
* Connect to RJ45 or digital input sensor ports
* Maximum cable length: 1000 ft.
ENVIROMUX-EBS Emergency/Panic Button
* Sends activation signal when button is pressed
* For Normally closed or open circuit connections
* Screw terminal connector on sensor
* Connect to RJ45 or digital input sensor ports
* Dimensions WxDxH (in.): 0.4x0.9x3
* Maximum cable length: 1000 ft.
ENVIROMUX-IMD Infrared Motion Sensor
* Registers movement in the area covered
* Condition display via LED
* Provides immunity from common-mode signals such as the effect of strong hot or cold air currents, variation in ambient
temperature, background radiation and acoustic noise
* 24 dual-element detection zones for long, mid and short range protections
* Surface or corner mounting
* Pulse count or single shot triggering
* Good RFI protection
* Connect to RJ45 or digital input sensor ports
* Screw terminal connector on sensor
* Maximum cable length 1000 ft.
