Digital Inputs

To view any digital input status screen, press <4> at the Monitoring Menu. The status screen contains a description, value, and
status for each input. Pressing any key will return the user to the Monitoring Menu. (View below is what will be seen with no
sensors connected.)
Digital Inputs Status
DESCRIPTION
--------------------------------------------
Press any key to continue

Output Relays

To view the output relay status screen, press <5> at the Monitoring Menu. The display shows the description of each relay, as well
as its value. Pressing any key will return the user to the Monitoring Menu.
Outputs Relays Status
DESCRIPTION
--------------------------------
Output Relay #1
--------------------------------
Output Relay #2
--------------------------------
Output Relay #3
--------------------------------
Output Relay #4
-------------------------------
Press any key to continue

Command Output Relays

To change the output relay status, press <6> at the Monitoring Menu. The display shows the description of each relay, as well as
its value. Typing <X> for exit, followed by <ENTER> will return the user to the Monitoring Menu.
Outputs Relays Status
# DESCRIPTION
-------------------------------------
1 Output Relay #1
-------------------------------------
2 Output Relay #2
-------------------------------------
3 Output Relay #3
-------------------------------------
4 Output Relay #4
-------------------------------------
Press number of Output Relay to change, or 'X' to exit
Enter Option >
Typing the number of a relay and pressing <ENTER> will allow the user to change the value of the relay from Closed to Open, as
shown below.
0-Open 1-Closed
Enter new value >
VALUE STATUS
VALUE
Closed
Closed
Closed
Closed
VALUE
Closed
Closed
Closed
Closed
