NTI SERVER ENVIRONMENT MONITORING SYSTEM

GSM Modem Connection

If alert notifications via SMS to a cell phone are desired, a GSM modem can be connected to the male 9DB DTE port labeled
"AUX". Using this serial connection, a user can receive SMS alert messages directly on their cell phone.
modem can be either self-powered or connected to 12V from the ENVIROMUX using the "AUX PWR" terminal.
ENVIROMUX is a DCE serial device.
GSM modems that have been tested and are confirmed to be compatible with the ENVIROMUX include:
Note: The GSM modem must be connected to ENVIROMUX and powered ON before powering ON the ENVIROMUX.
Note: The "AUX PWR" terminal is backed up by the battery inside ENVIROMUX.
WARNING
Device connected cannot
exceed 150mA contact
load.

Cascaded Installation via Direct Connection

For a cascaded installation using the Direct Connect method (see page 19), enabling the monitoring of all sensors from up to four
ENVIROMUX-SEMS-16 systems, connect a CAT5/5e/6 patch cable (maximum 25 feet long) with RJ45 male connectors on each
end (wired straight thru, pin 1 to pin 1, pin 2 to pin 2, etc.) between the "In" and "Out" ports as shown in the image below.
this properly connected the user can monitor the sensors of all systems from either a single connected terminal (page 13) or
through a single Web Interface (page 21).
NTI
R
NETWORK TECHNOLOGIES INC

Figure 13- Cascade up to 4 systems for centralized sensor monitoring

Enfora GSM1218 GPRS/GSM Modem
•
MultiTech Model MTCBA-G-F2 GPRS/GSM Modem
•
Wavecom Fastrack M1306 GSM Modem
•

Figure 12- Aux port and power for GSM modem connection

("Master with 3 Local Slaves" )
REAR VIEW OF ENVIROMUX-SEMS-16
1 2 3
RJ45 SENSORS
+ 12V + 12V + 12V + 12V
1275 Danner Dr, Aur ora, OH 44202 Tel:330-562-7070 ww w.networktechinc.com
NTI
R
NETWORK TECHNOLOGIES INC 1275 D anner Dr, Aurora, OH 44202
(Local Slave #2)
NTI
R
NETWORK TECHNOLOGIES INC
(Local Slave #3)
NTI
R
NETWORK TECHN OLOGIES IN C
A U X
DIGITAL IN
AUX
BEACON SIREN
4 5 6 7 8
+12V +12V
+ 12V + 12V + 12V + 12V
OUT
OUTPUT RELAYS
CONSOLE
1 2 3 4
IN
RJ45-male
connector
(Local Slave #1)
REAR VIEW OF ENVIROMUX-SEMS-16
DIG ITAL IN
BEACO N SI REN
1 2 3 4 5 6 7 8
RJ45 SENSO RS
+ 12V + 12V + 12V + 12V + 12V + 12V + 12V + 12V + 12 V +12V
OUT
DIGITAL OUT
1 2 3 4
Tel :330-562-7070 www. n etworktechinc. com
REAR VIEW OF ENVIROMUX-SEMS-16
DIG ITAL IN
BEACO N SI REN
1 2 3 4 5 6 7 8
RJ45 SENSO RS +12 V +12V
+ 12V + 12V + 12V + 12V + 12V + 12V + 12V + 12V
DIGITAL OUT
1 2 3 4
1275 D anner Dr, Aurora, OH 44202 Tel :330-562-7070 www. n etworktechinc. com
REAR VIEW OF ENVIROMUX-SEMS-16
DIG ITAL IN
1 2 3 4 5 6 7 8 BEACO N SIREN
RJ45 SENSORS +12V + 12 V
+ 12V + 12V + 12V + 12V + 12V + 12V + 12V + 12V
DIG ITAL OUT
1 2 3 4
1275 Danner Dr, Aurora, OH 44202 Tel :330-562- 7070 www. networkt echinc. com
14
The external GSM
The
A U X P W R
+ 1 2 V
AUX PWR
+12V
ETHERNET
RJ45-male
connector
AUX
AUX PWR
+12 V
CONSOLE
IN
ETHERNET
AUX AUX PWR
+12 V
OUT
CONSOLE
IN ETHERNET
AUX
AUX PWR
+12V
OUT
CONSOLE
I N ETHERNET
With
