Figure 26- Chart To Setup Alert Notification - Network Technologies ENVIROMUX-SEMS-16 Installation And Operation Manual

NTI SERVER ENVIRONMENT MONITORING SYSTEM
Fill in Network Page with valid information
(see page 37)
Create a user profile- be sure to include
valid user e-mail address and assign at
least one group to user to receive
messages from (page 41)
Configure sensor and assign sensor to a
group. For a user to receive messages
from this sensor, this group must be
selected in the user profile (above).
Use the "Simulate Alert" button to test the
sensor configuration. The sensor will send
a message to the assigned group.
The user will receive the message from the
group as configured in the alert notification
methods on the sensor configuration page
(page 29).

Figure 26- Chart to setup alert notification

30
