NTI SERVER ENVIRONMENT MONITORING SYSTEM

Door Contact Sensor

NTI Model #.................................................... ENVIROMUX-M-DCS
Connector.............................................. Screw Terminal
Alarm Output..................................................Magnetic Sensor; 35VDC/100mA
Max. Cable Length.........................................1000 ft

ACCESSORY SPECIFICATIONS

Digital Keypad

NTI Model #.................................................... ENVIROMUX-ACK
Connector ......................................................Screw Terminal
Voltage Supply...............................................12-24VDC
Current Consumption.....................................100mA
Alarm Output 1...............................................NC or NO dry contact, 30VDC/5A
Alarm Output 2...............................................NC or NO dry contact, 30VDC/1A
Duress ...........................................................NPN Open Collector; Active Low; 24VDC / 100mA
Tamper Switch...............................................NC dry contact, 50mA/24VDC
Max. Cable Length.........................................1000 ft

Key Station

NTI Model #.................................................... ENVIROMUX-RKS
Connector ......................................................Screw Terminal
Voltage Supply...............................................12VDC
Current Consumption.....................................12mA
Alarm Output..................................................N.O. Contact, 3A; Momentary
Tamper Switch...............................................NC dry contact, 12VDC/50mA
Max. Cable Length.........................................1000 ft

Electric Strike

NTI Model #....................................................ENVIROMUX-EDR-SF (Locked w/ Power ON)
....................................................ENVIROMUX-EDR-SCR (Locked w/ Power OFF)
Connector ......................................................Screw Terminal
Voltage Supply...............................................12VDC
Current Consumption.....................................450mA- SCR ; 200mA- SF
Max. Cable Length.........................................1000 ft

Alarm Beacon

NTI Model #.................................................... ENVIROMUX-BCN-R
Connector ......................................................Screw Terminal
Voltage Supply...............................................12VDC
Current Consumption.....................................180mA
Alarm Output..................................................60~80 Flashes per minute
Max. Cable Length.........................................100 ft
NOTE: The Electric Strike
should be connected to
DIGITAL IN terminal 8 for
power.
