DownStream Interfaces:
– VLAN: Lists the VID of the destination VLAN on the next-
hop multicast router.
Prune Reason: Identifies the reason for pruning the flow to the
–
indicated VLAN:
• Prune: A neighbor multicast router has sent a prune
• Assert: Another multicast router connected to the
• Other: Used where the VLAN is in the pruned state
ProCurve(config)# show ip pim mroute 239.255.255.1 10.27.30.2
PIM Route Entry
Group Address
Source Address : 10.27.30.2
Source Mask
Metric : 3
Metric Pref :
Assert Timer : 0
DownStream Interfaces
VLAN Prune Reason
---- ------------
28 pru ne
Figure 3-14. Example From Routing Switch "#1" in Figure 3-4 on Page 3-20
Showing a Multicast Group from a Directly Connected Source
Displaying PIM Data and Configuration Settings
request.
same VLAN has been elected to provide the path for
the specified multicast group traffic.
for any reason other than the above two reasons
(such as no neighbors exist and no directly con­
nected hosts have done joins).
: 239.255.255.1
: 255.255.255.0
120
PIM-DM (Dense Mode)
This example displays the MRT
data on the first of the two
multicast groups shown in figure
3-13 on page 3-32.
3-33
