ProCurve(pim)# show ip pim rp-candidate config
Status and Counters - PIM-SM Candidate-RP Information
C-RP Admin Status
Status Line
C-RP Address
C-RP Hold Time
C-RP Advertise Period
C-RP Priority
Configuration
C-RP Source IP VLAN
Group Address
--------------- ---------------
239.10.10.240
Figure 4-26. Example of the Full Candidate-RP Configuration Listing

Displaying Candidate-RP Data

Displaying the Router's Candidate-RP Status
and Configuration
Syntax: show ip pim rp-candidate [ config ]
rp-candidate: Lists the current Candidate-RP status and, if the
status is enabled for C-RP operation, includes the current C­
RP configuration on the router.
rp-candidate config: Lists the current Candidate-RP status and
the current C-RP configuration on the router, regardless of
whether C-RP operation is currently enabled.
ProCurve(pim)# show ip pim rp-candidate
This system is not a Candidate-RP
Figure 4-25. Example Listing for a Router that is Not Configured as a C-RP
Group Mask
255.255.255.252
Displaying PIM-SM Data and Configuration Settings
:
This system is not a Candidate-RP
: 120.10.10.2
: 150
:
60
: 192
:
120
PIM-SM (Sparse Mode)
Indicates that this
router is not enabled
for C-RP operation.
Example of a Candidate-RP
configuration for supporting
multicast groups in the range of
239.10.10.240 to 239.10.10.243.
4-63
