- Page 1 HP ProCurve 3500, 3500yl and 6200yl Switches Installation and Getting Started Guide Power over Ethernet...
- Page 3 HP ProCurve 3500, 3500yl and 6200yl Switches Installation and Getting Started Guide...
-
Page 4: Emc Regulatory Statements
HP ProCurve 10GbE 2-port SFP+ Module J9312A The only warranties for HP products and services are set forth in the express warranty statements accompanying 630 Redundant and/or External Power Supply J9443A such products and services. Nothing herein should be... -
Page 5: Table Of Contents
Power Connector ......... . 1-21 HP ProCurve Switch yl Modules ....... . . 1-22 Module Features . - Page 6 2 Installing the Switch Included Parts ..........2-1 Installation Procedures .
- Page 7 Downloading New Switch Software ......5-12 HP Customer Support Services ........5-12...
- Page 8 A Switch Specifications Physical ........... A-1 Electrical .
- Page 9 D Safety and EMC Regulatory Statements Safety Information ..........D-1 Informations concernant la sécurité...
-
Page 11: Introducing The Switch
Introducing the Switch The HP ProCurve 3500, 3500yl and 6200yl switches are multiport switches that can be used to build high-performance switched networks. These switches are store-and-forward devices offering low latency for high-speed networking. The 3500 and 3500yl switches also support Redundant Power Supply and Power over Ethernet (PoE/PoE+) technologies. -
Page 12: Poe Switches
Introducing the Switch PoE Switches HP ProCurve 3500-24-PoE Switch (J9471A) HP ProCurve 3500-48-PoE Switch (J9473A) HP ProCurve 3500yl-24G-PWR Switch (J8692A) PoE-Integrated 10/100/1000Base-T Ports (1 - 24T) — Ports are IEEE Auto MDI/MDI-X Dual-Personality Ports: 10/100/1000-T (T) or Mini-GBIC (M) ProCurve Switch... -
Page 13: Poe+ Switches
Introducing the Switch PoE+ Switches HP ProCurve 3500yl-24G-PoE+ Switch (J9310A) HP ProCurve 3500yl-48G-PoE+ Switch (J9311A) The 3500yl-24G-PoE+ switch has 20 auto-sensing 10/100Base-TX RJ-45 ports and 4 dual-personality ports—either auto-sensing 10/100/1000-T or SFP+ transceiver. The 3500yl-48G-PoE+ switch has 44 auto-sensing 10/100Base-TX RJ-45 ports and 4 dual-personality ports—either auto-sensing 10/100/1000-T or SFP+... - Page 14 Fiber (single mode) 10-Gig ER Fiber (single mode) For supported transceivers see www.hp.com/go/procurve/faqs. Both ProCurve 10-GbE, SFP/SFP+ transceivers and ProCurve Mini-GBICs have links to a list of supported products (first question in the “General Product Information” category). The 1000Base-T mini-GBIC is supported on the 6200yl only.
- Page 15 HP ProCurve Web site, www.hp.com/go/procurve/manuals. The 3500 and 3500yl switches can be connected to an HP ProCurve 620 Redundant and External Power Supply (RPS/EPS) and receive redundant power from that unit. If the internal power supply in the switch fails, the RPS/ EPS unit will immediately provide all the power necessary to keep the switch running.
-
Page 16: Front Of The Switches
10/100Base-TX RJ-45 ports (10/100/1000-T or SFP) Port LED Mode select Reset and Clear button and indicator LEDs buttons Figure 1-1. Front of the HP ProCurve 3500-24 Switch PoE, Temp, Fan, and Power, Test Status LEDs Fault, and Locator Switch port LEDs... - Page 17 Dual-personality ports ports (10/100/1000-T or SFP) Reset and Clear Port LED Mode select buttons button and indicator LEDs Figure 1-3. Front of the HP ProCurve 3500-24-PoE Switch PoE, Temp, Fan, and Power, Test Status LEDs Fault, and Locator Switch port LEDs...
- Page 18 Reset and Clear 10/100/1000Base-T RJ-45 (1000Base-T or mini-GBIC) buttons Port LED Mode select button and indicator LEDs Figure 1-5. Front of the HP ProCurve 3500yl-24G Switch PoE, Temp, Fan, and Power, Test Status LEDs Fault, and Locator Switch port LEDs...
- Page 19 10/100/1000Base-T Port LED Mode select (1000Base-T or mini-GBIC) port buttons RJ-45 ports button and indicator LEDs Figure 1-7. Front of the HP ProCurve 3500yl-24G-PoE+ Switch PoE, Temp, Fan, and Power, Test Status LEDs Fault, and Locator Switch port LEDs LEDs...
-
Page 20: Network Ports
Figure 1-9. Front of the HP ProCurve 6200yl-24G Switch Network Ports ■ All RJ-45 ports provide “HP Auto MDIX” features, which means you can use either straight-through or crossover twisted-pair cables to connect any network devices to the switch. ■... -
Page 21: Leds
Introducing the Switch Front of the Switches LEDs Table 1-2. Switch LEDs Switch State Meaning LEDs Power The switch is receiving power. (green) The switch is NOT receiving power. Fault The normal state; indicates there are no fault conditions on the switch. (orange) blink A fault has occurred on the switch, one of the switch ports, module in the rear of the... - Page 22 Introducing the Switch Front of the Switches Switch State Meaning LEDs Indicates the port LEDs are displaying the connection speed at which each port is operating: • if the port LED is off, the port is operating at 10 Mbps. •...
-
Page 23: Led Mode Select Button And Indicator Leds
Introducing the Switch Front of the Switches Switch State Meaning LEDs Temp Switch temperature is normal. (green/ Blink An over temperature condition has been detected. Orange) orange** Auxiliary Reserved for future development (green) * The blinking behavior is an on/off cycle once every 1.6 seconds, approximately. ** The blinking behavior is an on/off cycle once every 0.5 seconds, approximately. - Page 24 LED Mode select button and Mode and indicator LEDs Figure 1-12. Indicator LEDs on the HP ProCurve 6200yl-24G Switch Each port has a Link LED. If it is lit, the port has a link. If the Link LED is ■...
-
Page 25: Reset Button
Introducing the Switch Front of the Switches Reset Button This button is used to reset the switch while it is powered on. This action clears any temporary error conditions that may have occurred and executes the switch self test. It is also used when restoring the switch factory default configuration. -
Page 26: Expansion Module Leds
Introducing the Switch Front of the Switches Expansion Module LEDs “Expansion Module” LEDs refer to the LEDs specific to the expansion module. These LEDs are located on the physical expansion module bulkhead. These LEDs are only viewable in the rear of the 3500yl-48G and the 3500yl-48G-PoE+ product on the expansion slot module itself. -
Page 27: Back Of The Switch
Back of the Switch Back of the Switch Non-PoE Switches RPS Input Port AC power connector Figure 1-13. Back of the HP ProCurve 3500-24 Switch RPS Input Port AC power connector Console Port Auxiliary Port and LED Figure 1-14. Back of the HP ProCurve 3500-48 Switch Serial No. -
Page 28: Poe Switches
Introducing the Switch Back of the Switch PoE Switches EPS Input Port RPS Input Port AC power connector Figure 1-16. Back of the HP ProCurve 3500-24-PoE Switch EPS Input Port RPS Input Port AC power connector Console Port Auxiliary Port and LED Figure 1-17. -
Page 29: Poe+ Switches
200-240 V~ 5 A yl module slot AC power connector Auxiliary Port and LED RPS Input Port Console Port Figure 1-19. Back of the HP ProCurve 3500yl-48G Switch PoE+ Switches EPS Input Port RPS Input Port AC power connector yl module slot Figure 1-20. -
Page 30: Yl Module Slot
The 3500, 3500yl and 6200yl switches support connectivity to a redundant power supply. The “ProCurve 620 Redundant and External Power Supply (620 RPS/EPS) and the HP ProCurve 630 Redundant and/or External Power Supply (630 RPS/EPS) are accessory products for these Switches.
